Coppersensor 1 (Synonyms: CS1)

Cat. No.: HY-141511
Handling Instructions

Coppersensor-1 (CS1) is a boron dipyrromethene (BODIPY)-based fluorescent sensor for selective and sensitive detection of copper(I) ions (Cu+) in biological samples, including live cells.

For research use only. We do not sell to patients.

Coppersensor 1 Chemical Structure

Coppersensor 1 Chemical Structure

CAS No. : 874748-20-6

Size Stock
100 mg   Get quote
250 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

Top Publications Citing Use of Products
  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

Coppersensor-1 (CS1) is a boron dipyrromethene (BODIPY)-based fluorescent sensor for selective and sensitive detection of copper(I) ions (Cu+) in biological samples, including live cells[1].

In Vitro

Coppersensor 1 (CS1) comprising a boron dipyrromethene (BODIPY) chromophore coupled to a thioether-rich receptor, has a picomolar affinity for Cu+ with high selectivity over competing cellular metal ions. CS1 fluorescence increases up to 10-fold on binding to Cu+[1].
Guidelines[1] (Following is our recommended protocol. This protocol only provides a guideline, and should be modified according to your specific needs). 1. Coppersensor 1 (CS1) is dissolved in DMSO to obtain a 1 mM stock solution and further diluted before use. 2. cells are growing in medium, adding 10 mM CuCl2 stock solution to give a final copper concentration of 100 μM, and incubating for 1-8 h. 3. Adding competing chelator (N-ethyl-3,6,12,15-tetrathia-9-monoazaheptadecane; 100 mM) to copper-supplemented cells to give a final chelator concentration of 500 μM. Mix thoroughly, and incubate in the dark for 5 min at 25°C (A 5- to 10-fold excess of chelator over copper supplementation gives optimal results). 4. Cells are incubated with 1 mM Coppersensor 1 solution to give a final dye concentration of 5 mM. Mix thoroughly. (Higher concentrations of dye may result in high levels of background fluorescence.) Incubating for 5-20 min in the dark at 25°C or 37°C. 5. CS1 can be imaged using any type of fluorescence microscope, including epifluorescence, confocal and multiphoton. For standard confocal experiments, best results are obtained with 543 nm excitation to match the absorption maximum of the apo and Cu+-bound probe.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

629.81

Formula

C₃₀H₅₀BF₂N₃S₄

CAS No.
SMILES

[F-][B+3]1([N]2=C(C)C(CC)=C(C)C2=C(CN(CCSCCSCC)CCSCCSCC)C3=C(C)C(CC)=C(C)[N-]31)[F-]

Shipping

Room temperature in continental US; may vary elsewhere.

Storage

Please store the product under the recommended conditions in the Certificate of Analysis.

References
  • No file chosen (Maximum size is: 1024 Kb)
  • If you have published this work, please enter the PubMed ID.
  • Your name will appear on the site.
  • Molarity Calculator

  • Dilution Calculator

The molarity calculator equation

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass   Concentration   Volume   Molecular Weight *
= × ×

The dilution calculator equation

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)
× = ×
C1   V1   C2   V2
