SP2509

Cat. No.: HY-12635 Purity: 99.24%
Handling Instructions

SP2509 is a potent and selective antagonist of lysine specific demethylase 1 (LSD1) with IC50 of 13 nM.

For research use only. We do not sell to patients.

SP2509 Chemical Structure

SP2509 Chemical Structure

CAS No. : 1423715-09-6

Size Price Stock Quantity
Free Sample (0.5-1 mg)   Apply now
10 mM * 1 mL in DMSO USD 66 In-stock
Estimated Time of Arrival: December 31
5 mg USD 60 In-stock
Estimated Time of Arrival: December 31
10 mg USD 90 In-stock
Estimated Time of Arrival: December 31
50 mg USD 270 In-stock
Estimated Time of Arrival: December 31
100 mg USD 450 In-stock
Estimated Time of Arrival: December 31
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

Customer Review

Top Publications Citing Use of Products

    SP2509 purchased from MCE. Usage Cited in: Oncotarget. 2017 Aug 10;8(43):74434-74450.

    ARK2 and TOV112D cells are treated with an LSD1 inhibitor SP2509 (100 nM) for 24 h. Equal amounts of protein lysates are analyzed with western blots with appropriate antibodies. Increased levels of H3K4Me2 indicated an inhibition of LSD1. GAPDH is used to confirm that equal amounts of proteins are present in all lanes.
    • Biological Activity

    • Protocol

    • Technical Information

    • Purity & Documentation

    • References

    Description

    SP2509 is a potent and selective antagonist of lysine specific demethylase 1 (LSD1) with IC50 of 13 nM.

    IC50 & Target

    IC50: 13 nM (LSD1)[1]

    In Vitro

    SP2509 (250, 500, 1000 nM) inhibits LSD1 activity, depletes colony growth and induces apoptosis and cell death of cultured human acute myeloid leukemia cells, and increases H3K4Me3 on the promoters of p57 Kip, KLF4, and p21 and induces mRNA expression of p57Kip, KLF4 and p21 in AML cells. SP2509 (250, 1000 nM) induces features of morphologic differentiation of cultured and primary AML cells. Besides, SP2509 in combination with PS exerts synergistic lethal activity against cultured and primary AML cells[1]. SP2509 does not destabilize the CoREST-LSD1 interaction, and has no major destabilizing effect on the CRC. SP2509 (1 or 10 µM) induces cell death, but there are no morphological changes at a low concertation of 0.1 µM. SP2509 likewise interferes with the viability of medulloblastoma cells[2].

    In Vivo

    Treatment with SP2509 (25 mg/kg) and/or PS (5 mg/kg) significantly enhances PS-mediated loss of viability of CD34+ primary AML cells and improves the survival of mice bearing AML xenografts and primagrafts[2].

    Storage
    Powder -20°C 3 years
      4°C 2 years
    In solvent -80°C 6 months
      -20°C 1 month
    Solvent & Solubility
    In Vitro:

    DMSO : ≥ 33 mg/mL (75.36 mM)

    H2O : < 0.1 mg/mL (insoluble)

    *"≥" means soluble, but saturation unknown.

    Preparing
    Stock Solutions
    Concentration Solvent Mass 1 mg 5 mg 10 mg
    1 mM 2.2836 mL 11.4181 mL 22.8363 mL
    5 mM 0.4567 mL 2.2836 mL 4.5673 mL
    10 mM 0.2284 mL 1.1418 mL 2.2836 mL
    *Please refer to the solubility information to select the appropriate solvent.
    In Vivo:
    • 1.

      Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% saline

      Solubility: ≥ 2.08 mg/mL (4.75 mM); Clear solution

    *All of the co-solvents are provided by MCE.
    References
    Kinase Assay
    [2]

    To measure the activity of LSD1, a luminol-based assay is used. A total of 5 µL of eluate is diluted in LSD1 reaction buffer (50 mM Tris, pH 8.5, 50 mM KCl, 5 mM MgCl2, 5 nmol luminol, 20 μg/mL horseradish peroxidase, 1% Triton X-100), and 10 µM H3K4me2 (1-21 aa) peptide is added as the substrate. DMSO and inhibitors are added. The total volume per reaction is 100 µL. The samples are measured in a white 96-well plate using an EnSpire multimode plate reader at an emission wavelength of 428 nm. Three individual purifications (n = 3) are used for the assay, with three technical replicates for each.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Cell Assay
    [2]

    Daoy and D283 Med cells are used in the assay. ONS-76 cells are cultured in RPMI medium 1640 supplemented with 10% FBS, 50 U/mL penicillin, and 50 µg/mL streptomycin. All medulloblastoma cell lines are kept in an incubator at 37°C in a 5% CO2/5% O2/90% N2 atmosphere with maximum humidity. XTT assays are performed in triplicates (n = 3) with three replicates for each using 1×103 Daoy cells/well, 4×103 D283 Med cells/well, and 1×103 ONS-76 cells/well in 100 µL of medium at initial seeding in 96-well plates.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Animal Administration
    [1]

    Female NOD/SCID mice are exposed to 2.5 Gy of radiation. The following day, 5 million OCI-AmL3 cells are injected into the lateral tail vein of the mice and the mice are monitored for 7 days. Following treatments are administered in cohorts of 8 mice for each treatment: vehicle alone, 25 mg/kg SP2509, 5 mg/kg panobinostat and SP2509 plus panobinostat. Treatments are initiated on day 7 for OCI-AmL3 cells. SP2509 (formulated in solubilization buffer [20% Cremaphor, 20% DMSO, 60% sterile water]) is administered twice per week (Tues and Thurs) intraperitoneally (IP) for 3 weeks, and then discontinued. Panobinostat (formulated in 5% DMSO/ 95% normal saline) is administered by IP injection 3 days per week (M-W-F) for 3 weeks and discontinued. The doses of PS utilized in these studies are determined to be safe and effective. A separate in vivo experiment is conducted utilizing NSG mice and primary AmL cells. Following engraftment of the AmL cells (presence of greater than 1% CD45+ cells in the peripheral blood), mice are treated with SP2509 and/or PS, for three weeks.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    References
    Molecular Weight

    437.90

    Formula

    C₁₉H₂₀ClN₃O₅S

    CAS No.

    1423715-09-6

    SMILES

    O=C(N/N=C(C1=CC(Cl)=CC=C1O)\C)C2=CC=CC(S(=O)(N3CCOCC3)=O)=C2

    Shipping

    Room temperature in continental US; may vary elsewhere

    Purity: 99.24%

    • Molarity Calculator

    • Dilution Calculator

    The molarity calculator equation

    Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

    Mass   Concentration   Volume   Molecular Weight *
    = × ×

    The dilution calculator equation

    Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

    This equation is commonly abbreviated as: C1V1 = C2V2

    Concentration (start) × Volume (start) = Concentration (final) × Volume (final)
    × = ×
    C1   V1   C2   V2
