CU-CPT22 is a potent protein complex of toll-like receptor 1 and 2 (TLR1/2) inhibitor, and competes with the synthetic triacylated lipoprotein (Pam3CSK4) binding to TLR1/2 with a Ki of 0.41 µM. CU-CPT22 blocks Pam3CSK4-induced TLR1/2 activation with an IC50 of 0.58 µM.

For research use only. We do not sell to patients.

CU-CPT22 Chemical Structure

CU-CPT22 Chemical Structure

CAS No. : 1416324-85-0

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 143 In-stock
Solution
10 mM * 1 mL in DMSO USD 143 In-stock
Solid
5 mg USD 130 In-stock
10 mg USD 220 In-stock
25 mg USD 420 In-stock
50 mg USD 670 In-stock
100 mg USD 1050 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 8 publication(s) in Google Scholar

Top Publications Citing Use of Products

View All Toll-like Receptor (TLR) Isoform Specific Products:

  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

CU-CPT22 is a potent protein complex of toll-like receptor 1 and 2 (TLR1/2) inhibitor, and competes with the synthetic triacylated lipoprotein (Pam3CSK4) binding to TLR1/2 with a Ki of 0.41 µM. CU-CPT22 blocks Pam3CSK4-induced TLR1/2 activation with an IC50 of 0.58 µM[1].

IC50 & Target

TLR1



TLR2



In Vitro

CU-CPT22 is a toll-like receptor 1 and 2 (TLR1/2) inhibitor with an IC50 of 0.58±0.09 μM. It is demonstrated that CU-CPT22 is able to compete with Pam3CSK4 for binding to TLR1/2 with an inhibition constant (Ki) of 0.41±0.07 μM, which is consistent with its potency observed in the whole cell assay. Increasing the concentration of CU-CPT22 to 6 μM decreases the anisotropy to background levels. It is found that CU-CPT22 inhibits TLR1/2 signaling without affecting other TLRs, showing it is highly selective in intact cells. CU-CPT22 is found to have no significant cytotoxicity at various concentrations up to 100 μM in RAW 264.7 cells.? The result demonstrates that CU-CPT22 can inhibit about 60% of TNF-αand 95% of IL-1β at 8 μM[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

362.37

Formula

C19H22O7

CAS No.
Appearance

Solid

Color

Yellow to orange

SMILES

O=C(C(C=C1O)=CC2=CC(OC)=C(O)C(O)=C2C1=O)OCCCCCC

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 2 years
-20°C 1 year
Solvent & Solubility
In Vitro:

DMSO : ≥ 125 mg/mL (344.95 mM; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

*"≥" means soluble, but saturation unknown.

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.7596 mL 13.7981 mL 27.5961 mL
5 mM 0.5519 mL 2.7596 mL 5.5192 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 2.5 mg/mL (6.90 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: 2.5 mg/mL (6.90 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2.5 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: ≥99.0%

References
Kinase Assay
[1]

RAW 264.7 cells are planted in 6-well plates at 1,000,000 cells per well with 3 mL of medium and grown for 24 h at 37°C in a 5% CO2 humidified incubator. After 24 h, non-adherent cells and media are removed and replaced with fresh RPMI 1640 medium (3 mL/well). Two wells of adherent macrophages are treated with Pam3CSK4 (300 ng/mL) as the positive control, two wells are treated with 8 μM CU-CPT22, and the other two wells are treated with 8 μM compound DMSO. Plates are then incubated for an additional 24 h. The medium is removed, the cells are washed with PBS (3×1 mL), the plate is put on ice, then 500 μL of lysis buffer is added to each well. The production of the cytokine interleukin-1β (IL-1β) and TNF-α is quantified with enzyme-linked immunosorbent assays (ELISA). The cytokine level in each sample is determined in duplicate[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 2.7596 mL 13.7981 mL 27.5961 mL 68.9903 mL
5 mM 0.5519 mL 2.7596 mL 5.5192 mL 13.7981 mL
10 mM 0.2760 mL 1.3798 mL 2.7596 mL 6.8990 mL
15 mM 0.1840 mL 0.9199 mL 1.8397 mL 4.5994 mL
20 mM 0.1380 mL 0.6899 mL 1.3798 mL 3.4495 mL
25 mM 0.1104 mL 0.5519 mL 1.1038 mL 2.7596 mL
30 mM 0.0920 mL 0.4599 mL 0.9199 mL 2.2997 mL
40 mM 0.0690 mL 0.3450 mL 0.6899 mL 1.7248 mL
50 mM 0.0552 mL 0.2760 mL 0.5519 mL 1.3798 mL
60 mM 0.0460 mL 0.2300 mL 0.4599 mL 1.1498 mL
80 mM 0.0345 mL 0.1725 mL 0.3450 mL 0.8624 mL
100 mM 0.0276 mL 0.1380 mL 0.2760 mL 0.6899 mL
