CWHM-12 is a potent inhibitor of αV integrins with IC50s of 0.2, 0.8, 1.5, and 1.8 nM for αvβ8, αvβ3, αvβ6, and αvβ1.

For research use only. We do not sell to patients.

CWHM-12 Chemical Structure

CWHM-12 Chemical Structure

CAS No. : 1564286-55-0

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 130 In-stock
Solution
10 mM * 1 mL in DMSO USD 130 In-stock
Solid
5 mg USD 100 In-stock
10 mg USD 160 In-stock
50 mg USD 470 In-stock
100 mg USD 800 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 5 publication(s) in Google Scholar

Top Publications Citing Use of Products
  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

CWHM-12 is a potent inhibitor of αV integrins with IC50s of 0.2, 0.8, 1.5, and 1.8 nM for αvβ8, αvβ3, αvβ6, and αvβ1.

IC50 & Target

IC50: 0.2 nM (αvβ8), 0.8 nM (αvβ3), 1.5 nM (αvβ6), 1.8 nM (αvβ1), 61 nM (αvβ5)[1]

In Vitro

CWHM-12 (CWHM 12) also less potently inhibits αvβ5 (IC50=61 nM) and αIIbβ3/α2β1/α10β1 (IC50>5000 nM). CWHM-12 demonstrates high potency against all of the five possible β subunit binding partners (αvβ1, αvβ3, αvβ5, αvβ6 and αvβ8) in in vitro ligand-binding assays, with somewhat less potency against αvβ5 than against the other αv integrins[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

Mice are treated with CCl4 for 3 weeks to establish fibrotic disease and then treated with CWHM-12 (CWHM 12) or vehicle for the final 3 weeks of CCl4. CWHM-12 significantly reduces liver fibrosis even after fibrotic disease have been established. Digital image quantitation demonstrates significantly reduced p-SMAD3 signaling in the livers of CWHM-12 treated mice compare to controls, demonstrating that the protection from CCl4-induced hepatic fibrosis observed in CWHM-12 treated mice is due at least in part to a reduction in TGF-β activation by αv integrins. Besides, administration of CWHM-12 significantly inhibited progression of pulmonary fibrosis[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

590.47

Formula

C26H32BrN5O6

CAS No.
Appearance

Solid

Color

White to light brown

SMILES

O=C(CNC(C1=CC(NC2=NCC(O)CN2)=CC(O)=C1)=O)N[C@H](C3=CC(C(C)(C)C)=CC(Br)=C3)CC(O)=O

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 2 years
-20°C 1 year
Solvent & Solubility
In Vitro:

DMSO : 100 mg/mL (169.36 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 1.6936 mL 8.4678 mL 16.9357 mL
5 mM 0.3387 mL 1.6936 mL 3.3871 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 2.08 mg/mL (3.52 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.08 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (20.8 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: ≥ 2.08 mg/mL (3.52 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.08 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (20.8 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.77%

References
Kinase Assay
[1]

Functions of integrins αvβ1, αvβ8, α2β1 and α10β1 are measured using cell-free receptor-ligand interaction assays using purified recombinant human integrins. Ligands used are human fibronectin for αvβ1, human LAP for αvβ8, bovine collagen II for α2β1, and murine laminin I for α10β1. 96-well plates are coated with the predetermined optimal concentration of ligand overnight, washed 3X with TBS+++ (25 mM Tris pH7.4, 137 mM NaCl, 2.7 mM KCl, 1 mM MgCl2, 1 mM MnCl2, 1mM CaCl2), and blocked with TBS+++/1%BSA. Purified integrin is diluted in TBS+++/0.1%BSA with or without compounds (e.g., CWHM-12), and the solution added to empty wells of the washed ligand-coated plate according to a standard template, with each sample repeated in triplicate. After incubation for 2 hr at room temperature, the plate is washed 3X with TBS+++. Biotin-labeled antibody against the αv subunit (αvβ1, αvβ8 assays) or β1 subunit (α2β1, α10β1 assays) is applied for 1 hr. The plate is washed 3X with TBS/0.1%BSA. Streptavidin-conjugated horseradish peroxidase is added to the wells, and the plate incubated for 20 min at room temperature. Following a 3X TBS+++ wash, bound integrin is detected using streptavidin-conjugated horseradish peroxidase and TMB substrate with absorbance measured at 650 nm. For assay of αIIbβ3 (IIbIIIa) function, plates are coated with the purified human integrin overnight, washed 3X with TBS+++, and blocked with TBS+++/1%BSA. Alexa Fluor647-labeled purified human fibrinogen is diluted in TBS+++/0.1%BSA with or without compounds, and the solutions are added to the integrin-coated plate. After 2 hr incubation, the plate is washed 3X with TBS+++, and bound ligand is detected by absorbance measured at 640/668nm. For all assays, concentration-response curves are constructed by non-linear regression analysis and IC50 values are calculated using GraphPad Prism software[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Cell Assay
[1]

The stably transfected human 293 cells over-expressing human αvβ3 or αvβ5 are pre-incubated in HBSS buffer containing 200 μM MnCl2 for 30 min at 37°C with 3-fold dilutions of compound (e.g., CWHM-12). Each sample is then added to triplicate wells of a 96-well plate which has been coated overnight at 4°C with a predetermined optimal concentration of purified vitronectin, washed, blocked by 1 hr incubation with BSA, and washed again. Cells are allowed to attach for 30 min at 37°C, and non-adherent cells are removed by washing. Remaining attached cells are measured by endogenous alkaline phosphatase activity using para-nitrophenyl phosphate and reading absorbance signal at 405 nM. The same procedure is used to measure adhesion of αvβ6-expressing human HT-29 cells to purified human latency associated peptide, and α5β1-expressing human K562 cells to human plasma fibronectin. In all cell-based assays, binding by the expected integrin is verified by testing activity of corresponding isotype-matched positive (function-blocking) and negative control antibodies[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Administration
[1]

Mice[1]
The mTmG (Td tomato/EGFP) and Ai14 (Rosa-CAG-LSL-tdTomato-WPRE) mice are used and crossed with Pdgfrb-Cre mice. Wild type C57/BL6 mice, Itgavflox/flox mice and itgb8flox/flox mice are used. Mice used for all experiments are 8-12 weeks old and are housed under specific pathogen-free conditions. For all studies CWHM-12 and CWHM-96 are solubilized in 50% DMSO (in sterile water) and dosed to 100 mg/kg/day. Drug or vehicle (50% DMSO) are delivered by implantable ALZET osmotic minipumps. For CCl4-induced fibrosis, pumps are inserted subcutaneously either before the first dose of CCl4 (prophylactic) or after 3 weeks of treatment (therapeutic) and livers are harvested after 6 weeks. For Bleomycin-induced fibrosis pumps are inserted 14 days after treatment with Bleomycin or saline and lungs are harvested at 28 days (therapeutic only).

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 1.6936 mL 8.4678 mL 16.9357 mL 42.3392 mL
5 mM 0.3387 mL 1.6936 mL 3.3871 mL 8.4678 mL
10 mM 0.1694 mL 0.8468 mL 1.6936 mL 4.2339 mL
15 mM 0.1129 mL 0.5645 mL 1.1290 mL 2.8226 mL
20 mM 0.0847 mL 0.4234 mL 0.8468 mL 2.1170 mL
25 mM 0.0677 mL 0.3387 mL 0.6774 mL 1.6936 mL
30 mM 0.0565 mL 0.2823 mL 0.5645 mL 1.4113 mL
40 mM 0.0423 mL 0.2117 mL 0.4234 mL 1.0585 mL
50 mM 0.0339 mL 0.1694 mL 0.3387 mL 0.8468 mL
60 mM 0.0282 mL 0.1411 mL 0.2823 mL 0.7057 mL
80 mM 0.0212 mL 0.1058 mL 0.2117 mL 0.5292 mL
100 mM 0.0169 mL 0.0847 mL 0.1694 mL 0.4234 mL
