Motolimod  (Synonyms: VTX-2337; VTX-378)

Cat. No.: HY-13773 Purity: 98.12%
COA Handling Instructions

Motolimod (VTX-2337;VTX-378) is a selective Toll-like receptor 8 (TLR8) agonist, with an EC50 of approximately 100 nM.

For research use only. We do not sell to patients.

Motolimod Chemical Structure

Motolimod Chemical Structure

CAS No. : 926927-61-9

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 166 In-stock
Solution
10 mM * 1 mL in DMSO USD 166 In-stock
Solid
5 mg USD 150 In-stock
10 mg USD 250 In-stock
25 mg USD 490 In-stock
50 mg USD 924 In-stock
100 mg   Get quote
200 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 9 publication(s) in Google Scholar

Top Publications Citing Use of Products

    Motolimod purchased from MedChemExpress. Usage Cited in: J Biol Chem. 2017 Feb 17;292(7):2805-2814.  [Abstract]

    IL-1β ELISAs of supernatants from THP1 that are pre-incubated with medium or the indicated TLR8 agonists CL075 (5 μg/mL) or VTX-2337 (10 μM) for 16 h and after 8 h incubation in TLR8 agonist-free medium stimulated with 0.5 mg/mL ABC or medium for additional 16 h, respectively.

    View All Toll-like Receptor (TLR) Isoform Specific Products:

    • Biological Activity

    • Protocol

    • Purity & Documentation

    • References

    • Customer Review

    Description

    Motolimod (VTX-2337;VTX-378) is a selective Toll-like receptor 8 (TLR8) agonist, with an EC50 of approximately 100 nM.

    IC50 & Target

    TLR8



    In Vitro

    Among the TLRs tested (TLR2, 3, 4, 5, 7, 8, and 9), Motolimod (VTX-2337) selectively activates TLR8. Motolimod stimulates the production of both TNFα (EC50=140±30 nM based on 10 donors) and IL-12 (EC50=120±30 nM based on 10 donors) in PBMCs. The EC50 value for MIP-1β induction is 60 nM for Motolimod[1].

    MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

    In Vivo

    Monkeys receive a subcutaneous injection of Motolimod (1 or 10 mg/kg), and plasma is collected predose, 6, 12, 24, and 96 h post-injection. For the 10 mg/kg dose, mean plasma levels of IL-1β increase from baseline levels of 0.5 pg/mL, up to 9.12±2.7 ng/mL (p<0.05, t-test) at 6 h post-administration of Motolimod (10 mg/kg). Circulating levels of IL-18 also increase from a baseline of ~ 1 pg/mL to 68.7±4.4 pg/mL (p<0.05, t-test) at 6 h in response to the Motolimod (VTX-2337) treatment (10 mg/kg). Levels of IL-6 are monitored, as this mediator is induced in response to TLR8 activation, but the release is independent of NLRP3 inflammasome activation. In addition, plasma levels of IFNγ are assessed as a measure of NK cell activation in response to Motolimod treatment[2].

    MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

    Clinical Trial
    Molecular Weight

    458.60

    Formula

    C28H34N4O2

    CAS No.
    Appearance

    Solid

    Color

    Light yellow to brown

    SMILES

    O=C(C1=CC2=CC=C(C3=CC=C(C(N4CCCC4)=O)C=C3)C=C2N=C(N)C1)N(CCC)CCC

    Shipping

    Room temperature in continental US; may vary elsewhere.

    Storage
    Powder -20°C 3 years
    4°C 2 years
    In solvent -80°C 2 years
    -20°C 1 year
    Solvent & Solubility
    In Vitro:

    DMSO : 50 mg/mL (109.03 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

    Preparing
    Stock Solutions
    Concentration Solvent Mass 1 mg 5 mg 10 mg
    1 mM 2.1805 mL 10.9027 mL 21.8055 mL
    5 mM 0.4361 mL 2.1805 mL 4.3611 mL
    View the Complete Stock Solution Preparation Table

    * Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
    Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

    • Molarity Calculator

    • Dilution Calculator

    Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

    Mass
    =
    Concentration
    ×
    Volume
    ×
    Molecular Weight *

    Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

    This equation is commonly abbreviated as: C1V1 = C2V2

    Concentration (start)

    C1

    ×
    Volume (start)

    V1

    =
    Concentration (final)

    C2

    ×
    Volume (final)

    V2

    In Vivo:

    Select the appropriate dissolution method based on your experimental animal and administration route.

    For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
    To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
    The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

    • Protocol 1

      Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

      Solubility: ≥ 2.5 mg/mL (5.45 mM); Clear solution

      This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

      Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

      Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
    • Protocol 2

      Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

      Solubility: ≥ 2.5 mg/mL (5.45 mM); Clear solution

      This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

      Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

      Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
    In Vivo Dissolution Calculator
    Please enter the basic information of animal experiments:

    Dosage

    mg/kg

    Animal weight
    (per animal)

    g

    Dosing volume
    (per animal)

    μL

    Number of animals

    Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
    Please enter your animal formula composition:
    %
    DMSO +
    +
    %
    Tween-80 +
    %
    Saline
    Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
    The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
    Calculation results:
    Working solution concentration: mg/mL
    Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
    The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
    Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
     If the continuous dosing period exceeds half a month, please choose this protocol carefully.
    Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
    Purity & Documentation

    Purity: 98.12%

    References
    Kinase Assay
    [1]

    Human embryonic kidney cells (HEK293) expressing TLR2, 3, 4, 5, 7, 8, or 9 are cultured in Dulbecco's Modified Eagle's Media containing 4.5 g/L L-glucose and 10% FBS. The activity of specific TLR agonists is assessed using the secretory embryonic alkaline phosphatase (SEAP) reporter gene that is linked to NF-κB activation in response to TLR stimulation. Measurement of SEAP activity using the Quanti-blue substrate after TLR agonist treatment is carried out similarly[1].

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Cell Assay
    [1]

    PBMCs or purified NK cells are prepared, and the purity of NK cells is approximately 99%. NK cell-mediated cytotoxicity is assessed by Calcein AM release from labeled target cells. In brief, PBMCs or purified NK cells are cultured for 48 hours in RPMI medium in the presence of Motolimod (167 or 500 nM) before incubation with target cells[1].

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Animal Administration
    [2]

    Monkeys[2]
    The male monkeys (2.9-4.9 kg) are housed individually (cage dimensions of 0.76 m wide×0.74 m deep×0.81 m in height), but commingled periodically as part of the environmental enrichment program. The animals are also given fruit, vegetable, or additional supplements as a form of environmental enrichment, as well as given various cage enrichment devices. Animals are given Certified Primate Diet, two times daily and water ad libitum. Motolimod is administered as a bolus subcutaneous (SC) injection in the intrascapular area at doses of 1 and 10 mg/kg. Blood samples are collected at baseline (pre-dose), and 6, 12, 24, and 96 h post injection to monitor levels of IL-1β and IL-18 in the plasma using the human MAP v.1.6 inflammation panel.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    References

    Complete Stock Solution Preparation Table

    * Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
    Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

    Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
    DMSO 1 mM 2.1805 mL 10.9027 mL 21.8055 mL 54.5137 mL
    5 mM 0.4361 mL 2.1805 mL 4.3611 mL 10.9027 mL
    10 mM 0.2181 mL 1.0903 mL 2.1805 mL 5.4514 mL
    15 mM 0.1454 mL 0.7268 mL 1.4537 mL 3.6342 mL
    20 mM 0.1090 mL 0.5451 mL 1.0903 mL 2.7257 mL
    25 mM 0.0872 mL 0.4361 mL 0.8722 mL 2.1805 mL
    30 mM 0.0727 mL 0.3634 mL 0.7268 mL 1.8171 mL
    40 mM 0.0545 mL 0.2726 mL 0.5451 mL 1.3628 mL
    50 mM 0.0436 mL 0.2181 mL 0.4361 mL 1.0903 mL
    60 mM 0.0363 mL 0.1817 mL 0.3634 mL 0.9086 mL
    80 mM 0.0273 mL 0.1363 mL 0.2726 mL 0.6814 mL
    100 mM 0.0218 mL 0.1090 mL 0.2181 mL 0.5451 mL
