1. PI3K/Akt/mTOR Apoptosis
  2. PDK-1 Apoptosis
  3. BX-912

BX-912 is a direct, selective, and ATP-competitive PDK1 inhibitor (IC50=26 nM). BX-912 blocks PDK1/Akt signaling in tumor cells and inhibits the anchorage-dependent growth of a variety of tumor cell lines in culture or induces apoptosis.

For research use only. We do not sell to patients.

BX-912 Chemical Structure

BX-912 Chemical Structure

CAS No. : 702674-56-4

Size Price Stock Quantity
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 106 In-stock
Solution
10 mM * 1 mL in DMSO USD 106 In-stock
Solid
1 mg USD 70 In-stock
5 mg USD 102 In-stock
10 mg USD 180 In-stock
25 mg USD 380 In-stock
50 mg USD 630 In-stock
100 mg USD 950 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 5 publication(s) in Google Scholar

Top Publications Citing Use of Products
  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

BX-912 is a direct, selective, and ATP-competitive PDK1 inhibitor (IC50=26 nM). BX-912 blocks PDK1/Akt signaling in tumor cells and inhibits the anchorage-dependent growth of a variety of tumor cell lines in culture or induces apoptosis[1].

IC50 & Target

IC50: 26 nM (PDK1)[1]

In Vitro

BX-912 promotes a block at the G2/M phase of the cell cycle in MDA-468 cells[1].
BX-912 binds to the ATP binding site of PDK1, and is 9-fold selective for PDK1 relative to PKA. BX-912 blocks PDK1 activity in PTEN-negative PC-3 cells. PTEN-negative PC-3 cells display constitutive activation of Akt which is reflected in high levels of the PDK1 product, phospho-Thr308-Akt[1].
BX-912 is identified in a coupled assay measuring PDK1- and PtdIns-3,4-P2-mediated Akt activation, which can detect inhibitors of PDK1, AKT2, or other steps critical for activation of AKT2[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

471.35

Formula

C20H23BrN8O

CAS No.
Appearance

Solid

Color

White to off-white

SMILES

BrC1=C(NCCC2=CNC=N2)N=C(NC3=CC(NC(N4CCCC4)=O)=CC=C3)N=C1

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 2 years
-20°C 1 year
Solvent & Solubility
In Vitro:

DMSO : ≥ 100 mg/mL (212.16 mM; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

*"≥" means soluble, but saturation unknown.

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.1216 mL 10.6078 mL 21.2157 mL
5 mM 0.4243 mL 2.1216 mL 4.2431 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 2.75 mg/mL (5.83 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.75 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (27.5 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: ≥ 2.75 mg/mL (5.83 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.75 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (27.5 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.13%

References
Kinase Assay
[1]

PDK1 is assayed in a direct kinase assay and a coupled assay format measuring PDK1 and PtdIns-3,4-P2 mediated activation of AKT2. For the coupled assay, the final assay mixture (60 μL) contains: 15 mM MOPS, pH 7.2, 1 mg/mL bovine serum albumin, 18 mM β-glycerol phosphate, 0.7 mM dithiothreitol, 3 mM EGTA, 10 mM MgOAc, 7.5 μM ATP, 0.2 μCi of [γ-33P]ATP, 7.5 μM biotinylated peptide substrate (biotin-ARRRDGGGAQPFRPRAATF), 0.5 μL of PtdIns-3,4-P2-containing phospholipid vesicles, 60 pg of purified recombinant human PDK1, and 172 ng of purified recombinant human AKT2. After incubation for 2 h at room temperature, the biotin-labeled peptide is captured from 10 μL of the assay mixture on Streptavidin-coated SPA beads, and product formation is measured by scintillation proximity in a Wallac MicroBeta counter. The product formed is proportional to the time of incubation and to the amount of PDK1 and inactive AKT2 added. PDK1 is added at suboptimal levels so that the assay can sensitively detect inhibitors of AKT2 activation as well as direct inhibitors of PDK1 or AKT2[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Cell Assay
[1]

The cell lines MDA-468, MDA-453, HCT-116, U87-MG, U2OS, PC-3, B16F10, and MiaPaCa; LOX amelanotic human melanoma cells; and HeLa cells seeded at a low density (1,500-3,000 cells/well, 0.1 mL/well, 96-well plates) are incubated overnight. Compound treatments are made by adding 10 μL/well of BX-912 (1, 10, 100 and 1000 nM) in 1% DMSO and growth medium (final concentration of DMSO, 0.1%), followed by brief shaking. Treated cells are incubated for 72 h, and viability is measured by the addition of 10 μL of the metabolic dye WST-1. The WST-1 signal is read in a plate reader at 450 nm, and a no cell, or zero time cell, background is subtracted to calculate the net signal[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 2.1216 mL 10.6078 mL 21.2157 mL 53.0391 mL
5 mM 0.4243 mL 2.1216 mL 4.2431 mL 10.6078 mL
10 mM 0.2122 mL 1.0608 mL 2.1216 mL 5.3039 mL
15 mM 0.1414 mL 0.7072 mL 1.4144 mL 3.5359 mL
20 mM 0.1061 mL 0.5304 mL 1.0608 mL 2.6520 mL
25 mM 0.0849 mL 0.4243 mL 0.8486 mL 2.1216 mL
30 mM 0.0707 mL 0.3536 mL 0.7072 mL 1.7680 mL
40 mM 0.0530 mL 0.2652 mL 0.5304 mL 1.3260 mL
50 mM 0.0424 mL 0.2122 mL 0.4243 mL 1.0608 mL
60 mM 0.0354 mL 0.1768 mL 0.3536 mL 0.8840 mL
80 mM 0.0265 mL 0.1326 mL 0.2652 mL 0.6630 mL
100 mM 0.0212 mL 0.1061 mL 0.2122 mL 0.5304 mL
