PLX-4720 is a potent and selective inhibitor of B-RafV600E with IC50 of 13 nM in a cell-free assay, equally potent to c-Raf-1(Y340D and Y341D mutations), and 10-fold selectivity for B-RafV600E than wild-type B-Raf.

For research use only. We do not sell to patients.

PLX-4720 Chemical Structure

PLX-4720 Chemical Structure

CAS No. : 918505-84-7

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 68 In-stock
Solution
10 mM * 1 mL in DMSO USD 68 In-stock
Solid
5 mg USD 40 In-stock
10 mg USD 62 In-stock
50 mg USD 132 In-stock
100 mg   Get quote
200 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 9 publication(s) in Google Scholar

Other Forms of PLX-4720:

Top Publications Citing Use of Products

    PLX-4720 purchased from MedChemExpress. Usage Cited in: J Clin Invest. 2018 Aug 31;128(9):3976-3990.  [Abstract]

    NRP1 expression assessed by immunoblotting in parental and PLX-4720-resistant A375 cells transfected with pre-miRNA-338 (or mock transfected).

    View All Raf Isoform Specific Products:

    • Biological Activity

    • Protocol

    • Purity & Documentation

    • References

    • Customer Review

    Description

    PLX-4720 is a potent and selective inhibitor of B-RafV600E with IC50 of 13 nM in a cell-free assay, equally potent to c-Raf-1(Y340D and Y341D mutations), and 10-fold selectivity for B-RafV600E than wild-type B-Raf.

    IC50 & Target[1]

    B-RafV600E

    13 nM (IC50)

    B-Raf

    160 nM (IC50)

    BRK

    130 nM (IC50)

    FRK

    1300 nM (IC50)

    Csk

    1500 nM (IC50)

    Src

    1700 nM (IC50)

    FAK

    1700 nM (IC50)

    FGFR

    1900 nM (IC50)

    KDR

    2300 nM (IC50)

    HGK

    2800 nM (IC50)

    CSF1R

    3300 nM (IC50)

    Aurora A

    3400 nM (IC50)

    In Vitro

    PLX-4720 displays >10 times selectivity against wild type B-Raf, and >100 times selectivity over other kinases such as Frk, Src, Fak, FGFR, and Aurora A with IC50 of 1.3-3.4 μM. PLX-4720 significantly inhibits the ERK phosphorylation in cell lines bearing B-RafV600E with IC50 of 14-46 nM, but not the cells with wild-type B-Raf. PLX-4720 significantly inhibits the growth of tumor cell lines bearing the B-RafV600E oncogene, such as COLO205, A375, WM2664, and COLO829 with GI50 of 0.31 μM, 0.50 μM, 1.5 μM, and 1.7 μM, respectively. In addition, PLX-4720 treatment at 1 μM induces cell cycle arrest and apoptosis exclusively in the B-RafV600E-positive 1205Lu cells, but not in the B-Raf wild-type C8161 cells[1]. PLX-4720 treatment (10 μM) significantly induces > 14-fold expression of BIM in the PTEN+ cells, compared with the PTEN- cell lines (4-fold), giving an explanation of the resistance of PTEN- cells to PLX-4720-induced apoptosis[2].

    MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

    In Vivo

    Oral administration of PLX-4720 at 20 mg/kg/day induces significant tumor growth delays and regressions in B-RafV600E-dependent COLO205 tumor xenografts, without obvious adverse effects in mice even at dose of 1 g/kg. PLX-4720 at 100 mg/kg twice daily almost completely eliminates the 1205Lu xenografts bearing B-RafV600E, while has no activity against C8161 xenografts bearing wild-type B-Raf. The anti-tumor effects of PLX-4720 correlate with the blockade of MAPK pathway in those cells harboring the V600E mutation[1]. PLX-4720 treatment at 30 mg/kg/day significant inhibits the tumor growth of 8505c xenografts by >90%, and dramatically decreases distant lung metastases[3].

    MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

    Molecular Weight

    413.83

    Formula

    C17H14ClF2N3O3S

    CAS No.
    Appearance

    Solid

    Color

    White to off-white

    SMILES

    O=S(NC1=CC=C(C(C(C2=CNC3=NC=C(C=C23)Cl)=O)=C1F)F)(CCC)=O

    Shipping

    Room temperature in continental US; may vary elsewhere.

    Storage
    Powder -20°C 3 years
    4°C 2 years
    In solvent -80°C 2 years
    -20°C 1 year
    Solvent & Solubility
    In Vitro:

    DMSO : 100 mg/mL (241.65 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

    Preparing
    Stock Solutions
    Concentration Solvent Mass 1 mg 5 mg 10 mg
    1 mM 2.4165 mL 12.0823 mL 24.1645 mL
    5 mM 0.4833 mL 2.4165 mL 4.8329 mL
    View the Complete Stock Solution Preparation Table

    * Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
    Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

    • Molarity Calculator

    • Dilution Calculator

    Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

    Mass
    =
    Concentration
    ×
    Volume
    ×
    Molecular Weight *

    Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

    This equation is commonly abbreviated as: C1V1 = C2V2

    Concentration (start)

    C1

    ×
    Volume (start)

    V1

    =
    Concentration (final)

    C2

    ×
    Volume (final)

    V2

    In Vivo:

    Select the appropriate dissolution method based on your experimental animal and administration route.

    For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
    To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
    The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

    • Protocol 1

      Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

      Solubility: ≥ 2.08 mg/mL (5.03 mM); Clear solution

      This protocol yields a clear solution of ≥ 2.08 mg/mL (saturation unknown).

      Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (20.8 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

      Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
    • Protocol 2

      Add each solvent one by one:  10% DMSO    90% Corn Oil

      Solubility: ≥ 2.08 mg/mL (5.03 mM); Clear solution

      This protocol yields a clear solution of ≥ 2.08 mg/mL (saturation unknown). If the continuous dosing period exceeds half a month, please choose this protocol carefully.

      Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (20.8 mg/mL) to 900 μL Corn oil, and mix evenly.

    In Vivo Dissolution Calculator
    Please enter the basic information of animal experiments:

    Dosage

    mg/kg

    Animal weight
    (per animal)

    g

    Dosing volume
    (per animal)

    μL

    Number of animals

    Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
    Please enter your animal formula composition:
    %
    DMSO +
    +
    %
    Tween-80 +
    %
    Saline
    Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
    The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
    Calculation results:
    Working solution concentration: mg/mL
    Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
    The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
    Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
     If the continuous dosing period exceeds half a month, please choose this protocol carefully.
    Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
    Purity & Documentation

    Purity: 99.91%

    References
    Kinase Assay
    [1]

    For each enzyme (0.1 ng), 20-μL reactions are carried out in 20 mM Hepes (pH 7.0), 10 mM MgCl2, 1 mM DTT, 0.01% Tween-20, 100 nM biotin-MEK protein, various ATP concentrations, and increasing concentrations of PLX-4720 at room temperature. Reactions are stopped at 2, 5, 8, 10, 20, and 30 minutes with 5 μL of a solution containing 20 mM Hepes (pH 7.0), 200 mM NaCl, 80 mM EDTA, and 0.3% BSA. The stop solution also includes phospho-MEK Antibody, Streptavidin-coated Donor beads and Protein A Acceptor beads from the AlphaScreen Protein A Detection Kit. The antibody and beads are preincubated in stop solution in the dark at room temperature for 30 minutes. The final dilution of antibody is 1/2,000, and the final concentration of each bead is 10 μg/mL. The assay plates are incubated at room temperature for one hour then are read on a PerkinElmer AlphaQuest reader.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Cell Assay
    [1]

    Cells are treated with various concentrations PLX-4720 for 24, 48, and 72 hours. Cell proliferation is measured by using the CellTiter-Glo Luminescent Cell Viability Assay or MTT assay. For cell cycle analysis, supernatant and cells are collected, pelleted, and fixed with 70% ethanol. Before staining with propidium iodide (10 μg/mL), cells are incubated for 1 hour at 37°C in 0.5 mg/mL RNase I to rid samples of residual RNA contamination. Samples are then analyzed by using the EPICS XL apparatus. For the assessment of apoptosis, media and cells are harvested and pelleted before staining with annexin-FITC and propidium iodide. Samples are subsequently analyzed by using the EPICS XL apparatus.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Animal Administration
    [1]

    Metastatic melanoma cells (2×106) are s.c. injected into the flanks of SCID mice and allowed appr 2 weeks to reach 0.125 mm3 in volume. Subsequently, the animals receive either 100 mg/kg PLX4720 (oral gavage) or vehicle control twice daily for 15 days. Tumor volume is recorded every 72 h. The average tumor size for each respective group is normalized to the tumor volume at the first day of treatment. After 15 days of treatment, animals are killed and tumors are excised, fixed in formalin, paraffin-embedded, and analyzed by immunohistochemistry.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    References

    Complete Stock Solution Preparation Table

    * Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
    Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

    Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
    DMSO 1 mM 2.4165 mL 12.0823 mL 24.1645 mL 60.4113 mL
    5 mM 0.4833 mL 2.4165 mL 4.8329 mL 12.0823 mL
    10 mM 0.2416 mL 1.2082 mL 2.4165 mL 6.0411 mL
    15 mM 0.1611 mL 0.8055 mL 1.6110 mL 4.0274 mL
    20 mM 0.1208 mL 0.6041 mL 1.2082 mL 3.0206 mL
    25 mM 0.0967 mL 0.4833 mL 0.9666 mL 2.4165 mL
    30 mM 0.0805 mL 0.4027 mL 0.8055 mL 2.0137 mL
    40 mM 0.0604 mL 0.3021 mL 0.6041 mL 1.5103 mL
    50 mM 0.0483 mL 0.2416 mL 0.4833 mL 1.2082 mL
    60 mM 0.0403 mL 0.2014 mL 0.4027 mL 1.0069 mL
    80 mM 0.0302 mL 0.1510 mL 0.3021 mL 0.7551 mL
    100 mM 0.0242 mL 0.1208 mL 0.2416 mL 0.6041 mL
