1. Stem Cell/Wnt Cell Cycle/DNA Damage
  2. Wnt Porcupine Casein Kinase
  3. IWP-2

IWP-2 is an inhibitor of Wnt processing and secretion with an IC50 of 27 nM. IWP-2 targets the membrane-bound O-acyltransferase porcupine (Porcn) and thus preventing a crucial Wnt ligand palmitoylation. IWP-2 is also an ATP-competitive CK1δ inhibitor with an IC50 of 40 nM for the gatekeeper mutant M82FCK1δ.

For research use only. We do not sell to patients.

IWP-2 Chemical Structure

IWP-2 Chemical Structure

CAS No. : 686770-61-6

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
5 mg USD 55 In-stock
10 mg USD 88 In-stock
25 mg USD 176 In-stock
50 mg USD 286 In-stock
100 mg USD 451 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 13 publication(s) in Google Scholar

Other Forms of IWP-2:

Top Publications Citing Use of Products

View All Casein Kinase Isoform Specific Products:

  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

IWP-2 is an inhibitor of Wnt processing and secretion with an IC50 of 27 nM. IWP-2 targets the membrane-bound O-acyltransferase porcupine (Porcn) and thus preventing a crucial Wnt ligand palmitoylation. IWP-2 is also an ATP-competitive CK1δ inhibitor with an IC50 of 40 nM for the gatekeeper mutant M82FCK1δ[1][2].

IC50 & Target[1][2]

CK1δ

40 nM (IC50)

In Vitro

IWP-2 inhibits the proliferation of the investigated cell lines within the single digit μM range. IWP-2 inhibits cell proliferation in A818-6, MiaPaCa2, Panc-1, Panc-89, HT29, HEK293, SW620 and Capan cell with EC50s of 8.96 μM, 1.90 μM, 2.33 μM, 3.86 μM, 4.67 μM, 2.76 μM, 1.90 μM and 2.05 μM, respectively[2].
Panc-1 cells are either untreated or treated with 2.33 μM IWP-2 for 48 h. In IWP-2 treated cells, the CK1δ kinase peak activity is reduced to approximately 66% residual activity compared to the activity in untreated cells, respectively. IWP-2 reduces the activity of CK1δ in Panc1 cells[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

To evaluate the efficacy of IWP-2 in vivo, 200 μL each of IWP-2-liposome or free liposome i separately injected into C57BL/6 mice intraperitoneally about 2 h before injection of a similar volume of either blue-dye-filled latex beads or E. coli DH5α. IWP-2 causes significant reduction in the uptake of blue beads as well as E. coli as assessed by CFUs in peritoneal lavage cells within 2 h. In addition, the levels of TNF-α and IL-6 in the lavage fluid of the corresponding mice are reduced by 2-4-fold compared with control values. Interestingly, IWP-2 even induces a considerable increase in secretion of the anti-inflammatory cytokine IL-10[3].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

466.60

Formula

C22H18N4O2S3

CAS No.
Appearance

Solid

SMILES

O=C(NC1=NC2=CC=C(C)C=C2S1)CSC3=NC(CCS4)=C4C(N3C5=CC=CC=C5)=O

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 6 months
-20°C 1 month
Solvent & Solubility
In Vitro:

DMF : 12.5 mg/mL (26.79 mM; ultrasonic and warming and heat to 60°C)

DMSO : 2 mg/mL (4.29 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.1432 mL 10.7158 mL 21.4316 mL
5 mM 0.4286 mL 2.1432 mL 4.2863 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 0.2 mg/mL (0.43 mM); Clear solution

    This protocol yields a clear solution of ≥ 0.2 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (2.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  5% DMSO    40% PEG300    5% Tween-80    50% Saline

    Solubility: ≥ 0.1 mg/mL (0.21 mM); Clear solution

For the following dissolution methods, please prepare the working solution directly. It is recommended to prepare fresh solutions and use them promptly within a short period of time.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  50% PEG300    50% Saline

    Solubility: 10 mg/mL (21.43 mM); Suspended solution; Need ultrasonic

In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.51%

References
Cell Assay
[2]

The human RCC cell lines 786O and Caki-2 (5×103) are seeded into 96-well plates. Cell viability is estimated by MST assay after Caki-2 acells are incubated with ncreasing concentrations of LEF together with 20 μM IWP-2 for 48 h.After treatment, 10 μL MTS is added into each well for 2 h incubation. The absorbance is measured using a model ELX800 Micro Plate Reader at 490 nm. For colony formation assay, Caki-2 cells are trypsinized to single cell suspensions and seeded into fresh 6-well plates at 1000 cells/well. Then cells are incubated with LEF at depicted concentrations for 7 days. Colonies are fixed with absolute methanol for 15 min and then stained with 0.1% crystal violet for 20 min. After washing with PBS three times, the colonies with a diameter over 2 mm are visualized by a digital camera[2].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Administration

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO / DMF 1 mM 2.1432 mL 10.7158 mL 21.4316 mL 53.5791 mL
DMF 5 mM 0.4286 mL 2.1432 mL 4.2863 mL 10.7158 mL
10 mM 0.2143 mL 1.0716 mL 2.1432 mL 5.3579 mL
15 mM 0.1429 mL 0.7144 mL 1.4288 mL 3.5719 mL
20 mM 0.1072 mL 0.5358 mL 1.0716 mL 2.6790 mL
25 mM 0.0857 mL 0.4286 mL 0.8573 mL 2.1432 mL
