Motesanib Diphosphate (Synonyms: AMG 706 Diphosphate)

Cat. No.: HY-10229 Purity: 99.64%
Handling Instructions

Motesanib Diphosphate (AMG 706 Diphosphate) is a potent ATP-competitive inhibitor of VEGFR1/2/3 with IC50s of 2 nM/3 nM/6 nM, respectively, and has similar activity against Kit, and is approximately 10-fold more selective for VEGFR than PDGFR and Ret.

For research use only. We do not sell to patients.

Motesanib Diphosphate Chemical Structure

Motesanib Diphosphate Chemical Structure

CAS No. : 857876-30-3

Size Price Stock Quantity
Free Sample (0.5-1 mg)   Apply now
10 mM * 1 mL in DMSO USD 66 In-stock
Estimated Time of Arrival: December 31
10 mg USD 60 In-stock
Estimated Time of Arrival: December 31
50 mg USD 192 In-stock
Estimated Time of Arrival: December 31
100 mg USD 336 In-stock
Estimated Time of Arrival: December 31
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

Customer Review

Based on 5 publication(s) in Google Scholar

Other Forms of Motesanib Diphosphate:

Top Publications Citing Use of Products

    Motesanib Diphosphate purchased from MCE. Usage Cited in: Cell Physiol Biochem. 2018;48(1):227-236.

    Immunostaining of CD31 and α-SMA for the analysis of vessel density in infarcted heart.

    View All VEGFR Isoform Specific Products:

    • Biological Activity

    • Protocol

    • Purity & Documentation

    • References

    • Customer Review

    Description

    Motesanib Diphosphate (AMG 706 Diphosphate) is a potent ATP-competitive inhibitor of VEGFR1/2/3 with IC50s of 2 nM/3 nM/6 nM, respectively, and has similar activity against Kit, and is approximately 10-fold more selective for VEGFR than PDGFR and Ret.

    IC50 & Target[1]

    VEGFR1

    2 nM (IC50)

    VEGFR2

    3 nM (IC50)

    VEGFR3

    6 nM (IC50)

    In Vitro

    Motesanib Diphosphate (AMG 706 Diphosphate) has broad activity against the human VEGFR family, and displays over 1000-fold selectivity against EGFR, Src, and p38 kinase.Motesanib Diphosphate (AMG 706 Diphosphate) significantly inhibits VEGF-induced cellular proliferation of HUVECs with an IC50 of 10 nM, while displaying little effect at bFGF-induced proliferation with an IC50 of >3,000 nM. Motesanib Diphosphate (AMG 706 Diphosphate) also potently inhibits PDGF-induced proliferation and SCF-induced c-kit phosphorylation with IC50 of 207 nM and 37 nM, respectively, but not effective against the EGF-induced EGFR phosphorylation and cell viability of A431 cells[1]. Although displaying little antiproliferative activity on cell growth of HUVECs alone, Motesanib Diphosphate (AMG 706 Diphosphate) treatment significantly sensitizes the cells to fractionated radiation[2].

    In Vivo

    Motesanib Diphosphate (AMG 706 Diphosphate) (100 mg/kg) significantly inhibits VEGF-induced vascular permeability in a time-dependent manner. Oral administration of Motesanib twice daily or once daily potently inhibits, in a dose-dependent manner, VEGF-induced angiogenesis using the rat corneal model with ED50 of 2.1 mg/kg and 4.9 mg/kg, respectively. Motesanib Diphosphate (AMG 706 Diphosphate) induces a dose-dependent tumor regression of established A431 xenografts by selectively targeting neovascularization in tumor cells[1]. Motesanib Diphosphate (AMG 706 Diphosphate) in combination with radiation displays significant anti-tumor activity in head and neck squamous cell carcinoma (HNSCC) xenograft models[2]. Motesanib Diphosphate (AMG 706 Diphosphate) treatment also induces significant dose-dependent reductions in tumor growth and blood vessel density of MCF-7, MDA-MB-231, or Cal-51 xenografts, which can be markedly enhanced when combined with docetaxel or tamoxifen[3].

    Clinical Trial
    Molecular Weight

    569.44

    Formula

    C₂₂H₂₉N₅O₉P₂

    CAS No.

    857876-30-3

    SMILES

    O=C(C1=CC=CN=C1NCC2=CC=NC=C2)NC3=CC(NCC4(C)C)=C4C=C3.O=P(O)(O)O.O=P(O)(O)O

    Shipping

    Room temperature in continental US; may vary elsewhere

    Storage
    Powder -20°C 3 years
      4°C 2 years
    In solvent -80°C 6 months
      -20°C 1 month
    Solvent & Solubility
    In Vitro:

    DMSO : ≥ 110 mg/mL (193.17 mM)

    *"≥" means soluble, but saturation unknown.

    Preparing
    Stock Solutions
    Concentration Solvent Mass 1 mg 5 mg 10 mg
    1 mM 1.7561 mL 8.7806 mL 17.5611 mL
    5 mM 0.3512 mL 1.7561 mL 3.5122 mL
    10 mM 0.1756 mL 0.8781 mL 1.7561 mL
    *Please refer to the solubility information to select the appropriate solvent.
    In Vivo:
    • 1.

      Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% saline

      Solubility: ≥ 2.5 mg/mL (4.39 mM); Clear solution

    • 2.

      Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in saline)

      Solubility: ≥ 2.5 mg/mL (4.39 mM); Clear solution

    • 3.

      Add each solvent one by one:  10% DMSO    90% corn oil

      Solubility: ≥ 25 mg/mL (43.90 mM); Clear solution

    *All of the co-solvents are provided by MCE.
    References
    Kinase Assay
    [1]

    Optimal enzyme, ATP, and substrate (gastrin peptide) concentrations are established for each enzyme using homogeneous time-resolved fluorescence (HTRF) assays. Motesanib is tested in a 10-point dose-response curve for each enzyme using an ATP concentration of two-thirds Km for each. Most assays consist of enzyme mixed with kinase reaction buffer [20 mM Tris-HCl (pH 7.5), 10 mM MgCl2, 5 mM MnCl2, 100 mM NaCl, 1.5 mM EGTA]. A final concentration of 1 mM DTT, 0.2 mM NaVO4, and 20 μg/mL BSA is added before each assay. For all assays, 5.75 mg/mL streptavidin-allophycocyanin and 0.1125 nM Eu-PT66 are added immediately before the HTRF reaction. Plates are incubated for 30 minutes at room temperature and read on a Discovery instrument. IC50 values are calculated using the Levenberg-Marquardt algorithm into a four-parameter logistic equation.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Cell Assay
    [1]

    Cells are preincubated for 2 hours with different concentrations of Motesanib, and exposed with 50 ng/mL VEGF or 20 ng/mL bFGF for an additional 72 hours. Cells are washed twice with DPBS, and plates are frozen at -70°C for 24 hours. Proliferation is assessed by the addition of CyQuant dye, and plates are read on a Victor 1420 workstation. IC50 data are calculated using the Levenberg-Marquardt algorithm into a four-parameter logistic equatio.

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Animal Administration
    [1]

    A431 cells are cultured in DMEM (low glucose) with 10% FBS and penicillin/streptomycin/glutamine. Cells are harvested by trypsinization, washed, and adjusted to a concentration of 5×107/mL in serum-free medium. Animals are challenged s.c. with 1×107 cells in 0.2 mL over the left flank. Approximately 10 days thereafter, mice are randomized based on initial tumor volume measurements and treated with either vehicle (Ora-Plus) or Motesanib. Tumor volumes and body weights are recorded twice weekly and/or on the day of sacrifice. Tumor volume is measured with a Pro-Max electronic digital caliper and calculated using the formula length (mm)×width (mm)×height (mm) and expressed in mm3. Data are expressed as mean±SE. Repeated measures ANOVA followed by Scheffe post hoc testing for multiple comparisons is used to evaluate the statistical significance of observed differences[1].

    MCE has not independently confirmed the accuracy of these methods. They are for reference only.
