1. Protein Tyrosine Kinase/RTK
  2. VEGFR FGFR PDGFR
  3. SU 5402

SU 5402 is a potent multi-targeted receptor tyrosine kinase inhibitor with IC50 of 20 nM, 30 nM, and 510 nM for VEGFR2, FGFR1, and PDGFRβ, respectively.

For research use only. We do not sell to patients.

SU 5402 Chemical Structure

SU 5402 Chemical Structure

CAS No. : 215543-92-3

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 82 In-stock
Solution
10 mM * 1 mL in DMSO USD 82 In-stock
Solid
5 mg USD 74 In-stock
10 mg USD 115 In-stock
50 mg USD 345 In-stock
100 mg USD 550 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 9 publication(s) in Google Scholar

Other Forms of SU 5402:

Top Publications Citing Use of Products

View All VEGFR Isoform Specific Products:

View All FGFR Isoform Specific Products:

View All PDGFR Isoform Specific Products:

  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

SU 5402 is a potent multi-targeted receptor tyrosine kinase inhibitor with IC50 of 20 nM, 30 nM, and 510 nM for VEGFR2, FGFR1, and PDGFRβ, respectively.

IC50 & Target[1]

VEGFR2

20 nM (IC50)

FGFR1

30 nM (IC50)

PDGFRβ

510 nM (IC50)

In Vitro

SU 5402 is cocrystallized with the catalytic domain of FGF-R1 (flg-1) and is found to inhibit tyrosine phosphorylation of VEGF-R2 (Flk-1/KDR) and PDGF-R in NIH 3T3 cells with IC50 values of 0.4 and 60.9 μM, respectively[1]. In order to investigate whether phosphorylation of PKM2 and LDHA is mediated in FGFR1-specific manner, FTC-133 are treated with receptor tyrosine kinase inhibitors Dovitinib and SU 5402 (SU-5402). Dovitinib treatment results in significant decrease of phosphorylation status at a concentration of 100 nM after four hours of incubation for both PKM2 and LDHA. No significant changes are seen when administered at concentrations of 1 nM and 10 nM. SU 5402 administration leads to a sigificant decrease of PKM2 and LDHA phosphorylation at a concentration of 20 μM[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

Inhibition of FGFR1 with SU 5402 (SU5402) administered to ΔF508-CFTR homozygous mice results in partial ΔF508-CFTR rescue, as shown by an increase in saliva secretion, a surrogate "sweat test" assay in mice. As salivary secretion is often sex dependent, only male mice are chosen for these experiments. Our results indicate that treatment of the ΔF508-CFTR mice with SU 5402 restores the saliva secretion level to ~10% of that observed for the wild-type CFTR mice, which suggests that SU 5402 can have therapeutic benefits to Cystic Fibrosis (CF)[3]. The selective FGFR1 inhibitor SU 5402 (SU5402) prevents and/or reverses PH induced by MCT (monocrotaline) in rats. In rats treated with SU 5402 on days 21 to 42 after the MCT injection, evaluations on day 42 show marked decreases in pulmonary artery pressure (PAP), RV/(LV+S), and distal artery muscularization compare with rats treated with the vehicle (saline)[4].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

296.32

Formula

C17H16N2O3

CAS No.
Appearance

Solid

Color

Light brown to orange

SMILES

O=C(CCC1=C(NC=C1C)/C=C2C(NC3=C\2C=CC=C3)=O)O

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 6 months
-20°C 1 month
Solvent & Solubility
In Vitro:

DMSO : ≥ 30 mg/mL (101.24 mM; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

H2O : < 0.1 mg/mL (insoluble)

*"≥" means soluble, but saturation unknown.

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 3.3747 mL 16.8736 mL 33.7473 mL
5 mM 0.6749 mL 3.3747 mL 6.7495 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 2.5 mg/mL (8.44 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation
References
Cell Assay
[2]

8505C and FTC133 cells are grown in DMEM/F12 suppplemented with 10% FCS and 1% PenStrep and incubated at 37°C, 5% CO2. For B-CPAP RPMI 1640 medium is used. FGFR1 inhibition experiments are performed on FTC133 cells by employment of Receptor Tyrosine Kinase Inhibitors TKI-258 (Dovitinib) and SU 5402 (20μM). Inhibition is conducted over 4 h with the indicated inhibitor concentrations. Control cells receive corresponding concentrations of DMSO[2].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Administration
[3][4]

Mice[3]
Male ΔF508 mice (CFTRtm1Eur on a 129/FVB background) and their wild-type littermates of 9-12 weeks are intraperitoneally injected with DMSO or SU 5402 (dissolved in DMSO at the concentration of 6 mg/mL) at 25 mg/kg body weight, every day for 1 week. The mice are weighed daily and the dosages adjusted accordingly. The mice are then anesthetized by inhaling isoflurane until the end of the procedure. Cholinergic antagonist, Atropine (1 mM, 50 μL) is subcutaneously injected into the right cheek to block potential cholinergic stimulation of the salivary gland. A small strip of filter paper is placed against the injected cheek, for 4 min. Isoprenaline (10 mM, 37.5 μL) is subsequently injected in the same spot to stimulate an adrenergic secretion of saliva (time 0). Filter strips (pre-weighed in an Eppendorf tube) are replaced every 5 min, over a period of 30 min. All six filter strips are weighed at the end of the collection and the results are normalized relative to mg/g body weight.
Rats[4]
To assess the potential effects of the FGFR1 inhibitor SU 5402 on established PH, adult male Wistar rats (200-250 g) are given MCT (60 mg/kg s.c.), left untreated for 21 days, then randomly divided into 2 groups (10 animals in each group), of which one is treated with SU 5402 (25 mg/kg/day) and the other given the vehicle, from day 21 to day 42. All treatments are given once a day by s.c. injection.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 3.3747 mL 16.8736 mL 33.7473 mL 84.3682 mL
5 mM 0.6749 mL 3.3747 mL 6.7495 mL 16.8736 mL
10 mM 0.3375 mL 1.6874 mL 3.3747 mL 8.4368 mL
15 mM 0.2250 mL 1.1249 mL 2.2498 mL 5.6245 mL
20 mM 0.1687 mL 0.8437 mL 1.6874 mL 4.2184 mL
25 mM 0.1350 mL 0.6749 mL 1.3499 mL 3.3747 mL
30 mM 0.1125 mL 0.5625 mL 1.1249 mL 2.8123 mL
40 mM 0.0844 mL 0.4218 mL 0.8437 mL 2.1092 mL
50 mM 0.0675 mL 0.3375 mL 0.6749 mL 1.6874 mL
60 mM 0.0562 mL 0.2812 mL 0.5625 mL 1.4061 mL
80 mM 0.0422 mL 0.2109 mL 0.4218 mL 1.0546 mL
100 mM 0.0337 mL 0.1687 mL 0.3375 mL 0.8437 mL
