GSK-690693

Cat. No.: HY-10249 Purity: 98.46%
COA Handling Instructions

GSK-690693 est un inhibiteur de pan-Akt qui est ATP- compétitif avec des IC50 de 2 nM, 13 nM, 9 nM pour Akt1, Akt2 et Akt3, respectivement. GSK-690693 est également un inhibiteur de AMPK, affecte l'activité de la kinase 1 (ULK1) activant l'autophagie de type Unc-51 et inhibe de manière robuste l'activation IRF3 dépendante de STING.

GSK-690693 is an ATP-competitive pan-Akt inhibitor with IC50s of 2 nM, 13 nM, 9 nM for Akt1, Akt2 and Akt3, respectively. GSK-690693 is also an AMPK inhibitor, affects Unc-51-like autophagy activating kinase 1 (ULK1) activity and robustly inhibits STING-dependent IRF3 activation.

For research use only. We do not sell to patients.

GSK-690693 Chemical Structure

GSK-690693 Chemical Structure

CAS No. : 937174-76-0

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
 USD 132 In-stock
Solution
10 mM * 1 mL in DMSO USD 132 In-stock
Solid
5 mg USD 120 In-stock
10 mg USD 169 In-stock
25 mg USD 338 In-stock
50 mg USD 540 In-stock
100 mg USD 865 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 29 publication(s) in Google Scholar

Other Forms of GSK-690693:

GSK-690693 Related Antibodies

Top Publications Citing Use of Products

View All Akt Isoform Specific Products:

View All Isoforms
Akt Akt1 Akt2 Akt3

View All AMPK Isoform Specific Products:

View All Isoforms
NUAK1 NUAK2 AMPK AMPK α1β1γ1 AMPK α2β1γ1 AMPK α1β2γ1 AMPK α2β2γ1

  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

GSK-690693 is an ATP-competitive pan-Akt inhibitor with IC50s of 2 nM, 13 nM, 9 nM for Akt1, Akt2 and Akt3, respectively. GSK-690693 is also an AMPK inhibitor, affects Unc-51-like autophagy activating kinase 1 (ULK1) activity and robustly inhibits STING-dependent IRF3 activation[1][2][3].

IC50 & Target[1]

Akt1

2 nM (IC50)

Akt3

9 nM (IC50)

Akt2

13 nM (IC50)

PKCη

2 nM (IC50)

PKCθ

2 nM (IC50)

PrkX

5 nM (IC50)

PAK6

6 nM (IC50)

PAK4

10 nM (IC50)

PKCδ

14 nM (IC50)

PKCβ1

19 nM (IC50)

PKCε

21 nM (IC50)

PKA

24 nM (IC50)

PKG1β

33 nM (IC50)

AMPK

50 nM (IC50)

PAK5

52 nM (IC50)

DAPK3

81 nM (IC50)

Autophagy



In Vitro

GSK690693 is very selective for the Akt isoforms versus the majority of kinases in other families. However, GSK690693 is less selective for members of the AGC kinase family including PKA, PrkX, and PKC isozymes with IC50 of 24 nM, 5 nM, and 2-21 nM, respectively. GSK690693 also potently inhibits AMPK and DAPK3 from the CAMK family with IC50 of 50 nM and 81 nM, respectively, and PAK4, 5, and 6 from the STE family with IC50 of 10 nM, 52 nM, and 6 nM, respectively. GSK690693 inhibits the phosphorylation of GSK3β in tumor cells with IC50 ranging from 43 nM to 150 nM. GSK690693 treatment leads to a dose-dependent increase in the nuclear accumulation of the transcription factor FOXO3A. GSK690693 potently inhibits the proliferation of T47D, ZR-75-1, BT474, HCC1954, MDA-MB-453, and LNCaP cells with IC50 of 72 nM, 79 nM, 86 nM, 119 nM, 975 nM, and 147 nM, respectively. GSK690693 treatment induces apoptosis at concentrations > 100 nM in both LNCaP and BT474 cells[1]. Consistent with the role of AKT in cell survival, GSK690693 induces apoptosis in sensitive ALL cell lines[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

GSK-690693 Related Antibodies
In Vivo

A single administration of GSK690693 inhibits GSK3β phosphorylation in human breast carcinoma (BT474) xenografts in a dose- and time-dependent manner. Similarly, GSK690693 induces a reduction in phosphorylation of the Akt substrates, PRAS40, and FKHR/FKHRL1. GSK690693 also results in an acute increase in blood glucose, returning to baseline 8 to 10 hours after drug administration. Administration of GSK690693 induces reductions in phosphorylated Akt substrates in vivo, and potently inhibits the growth of human SKOV-3 ovarian, LNCaP prostate, and BT474 and HCC-1954 breast carcinoma xenografts, with maximal inhibition of 58% to 75% at the dose of 30 mg/kg/day[1]. GSK690693 exhibits efficacy irrespective of the mechanism of Akt activation involved. GSK690693 is most effective in delaying tumor progression in Lck-MyrAkt2 mice expressing a membrane-bound, constitutively active form of Akt[3].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.
Clinical Trial
Molecular Weight

425.48

Appearance

Solid

Formula

C21H27N7O3
CAS No.
SMILES

CC(O)(C)C#CC1=NC=C(OC[C@@H]2CNCCC2)C3=C1N=C(C4=NON=C4N)N3CC
Shipping

Room temperature in continental US; may vary elsewhere.
Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 1 year
-20°C 6 months
Solvent & Solubility
In Vitro:

DMSO : 20 mg/mL (47.01 mM; ultrasonic and warming and heat to 60°C)

H2O : 5 mg/mL (11.75 mM; ultrasonic and adjust pH to 5 with HCl)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.3503 mL 11.7514 mL 23.5029 mL
5 mM 0.4701 mL 2.3503 mL 4.7006 mL
10 mM 0.2350 mL 1.1751 mL 2.3503 mL
*Please refer to the solubility information to select the appropriate solvent.
In Vivo:
  • 1.

    Add each solvent one by one:  20% HP-β-CD/10 mM citrate pH 2.0

    Solubility: 10 mg/mL (23.50 mM); Clear solution; Need ultrasonic

  • 2.

    Add each solvent one by one:  10% DMSO    90% Corn Oil

    Solubility: ≥ 2.5 mg/mL (5.88 mM); Clear solution

  • 3.

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: 2 mg/mL (4.70 mM); Clear solution; Need ultrasonic

  • 4.

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: 2 mg/mL (4.70 mM); Suspended solution; Need ultrasonic

*All of the co-solvents are available by MedChemExpress (MCE).
Purity & Documentation

Purity: 98.46%

COA (250 KB) RP-HPLC (247 KB)

Handling Instructions (2659 KB)
References
Kinase Assay
[1]

His-tagged full-length Akt1, 2, or 3 are expressed and purified from baculovirus. Activation is carried out with purified PDK1 to phosphorylate Thr308 and purified MK2 to phosphorylate Ser473. To more accurately measure time-dependent inhibition of Akt, activated Akt enzymes are incubated with GSK690693 at various concentrations at room temperature for 30 minutes before the reaction is initiated with the addition of substrate. Final reaction contains 5 nM to 15 nM Akt1, 2, and 3 enzymes; 2 μM ATP; 0.15 μCi/μL[γ-33P]ATP; 1 μM Peptide (Biotin-aminohexanoicacid-ARKR-ERAYSFGHHA-amide); 10 mM MgCl2; 25 mM MOPS (pH 7.5); 1 mM DTT; 1 mM CHAPS; and 50 mM KCl. The reactions are incubated at room temperature for 45 minutes, followed by termination with Leadseeker beads in PBS containing EDTA (final concentration, 2 mg/mL beads and 75 mM EDTA). The plates are then sealed, the beads are allowed to settle for at least 5 hours, and product formation is quantitated using a Viewlux Imager.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.
Cell Assay
[1]

Cells are plated at densities that allow untreated cells to grow logarithmically during the course of a 3-day assay. Briefly, cells are plated in 96- or 384-well plates and incubated overnight. Cells are then treated with GSK690693 (ranging from 30 μM-1.5 nM) and incubated for 72 hours. Cell proliferation is measured using the CellTiter Glo reagent. Data are analyzed using the XLFit curve-fitting tool for Microsoft Excel. IC50 values are obtained by fitting data to Eq, 2.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.
Animal Administration
[1]

Tumors are initiated by injection of tumor cell suspension (HCC1954, MDA-MB-453, and LNCaP) or tumor fragments (BT474, SKOV-3, and PANC1) s.c. in 8- to 12-wk-old CD1 Swiss Nude mice (LNCaP, SKOV-3, and PANC1) or SCID mice (HCC1954, MDA-MB-453, and BT474). When tumors reach a volume of 100 to 200 mm3, mice are randomized and divided into groups of 8 to 12 mice per group. GSK690693 is administered once daily at 10, 20, and 30 mg/kg by i.p. administration. Animals are euthanized by inhalation of CO2 at the completion of the study. Tumor volume is measured twice weekly by calipers, using the equation: tumor volume (mm3)=(length × width2)/2. Results are reported as % inhibition on day 21 of treatment=100× [1-(average growth of the drug-treated population/average growth of vehicle-treated control population)]. Statistical analysis is done using two-tailed t test.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.
References
  • No file chosen (Maximum size is: 1024 Kb)
  • If you have published this work, please enter the PubMed ID.
  • Your name will appear on the site.

GSK-690693 Related Classifications

Help & FAQs
  • Do most proteins show cross-species activity?

    Species cross-reactivity must be investigated individually for each product. Many human cytokines will produce a nice response in mouse cell lines, and many mouse proteins will show activity on human cells. Other proteins may have a lower specific activity when used in the opposite species.

  • Molarity Calculator

  • Dilution Calculator

The molarity calculator equation

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass   Concentration   Volume   Molecular Weight *
= × ×

The dilution calculator equation

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)
× = ×
C1   V1   C2   V2
