1. Protein Tyrosine Kinase/RTK
  2. VEGFR
  3. Axitinib

Axitinib (Synonyms: AG-013736)

Cat. No.: HY-10065 Purity: 99.94%
Handling Instructions

Axitinib is a multi-targeted tyrosine kinase inhibitor with IC50s of 0.1, 0.2, 0.1-0.3, 1.6 nM for VEGFR1, VEGFR2, VEGFR3 and PDGFRβ, respectively.

For research use only. We do not sell to patients.

Axitinib Chemical Structure

Axitinib Chemical Structure

CAS No. : 319460-85-0

Size Stock
10 mM * 1 mL in DMSO Get quote
50 mg USD 72 Get quote
100 mg USD 102 Get quote
200 mg USD 132 Get quote
500 mg USD 264 Get quote

* Please select Quantity before adding items.

Customer Review

Top Publications Citing Use of Products

View All VEGFR Isoform Specific Products:

View All PDGFR Isoform Specific Products:

  • Biological Activity

  • Protocol

  • Technical Information

  • Purity & Documentation

  • References


Axitinib is a multi-targeted tyrosine kinase inhibitor with IC50s of 0.1, 0.2, 0.1-0.3, 1.6 nM for VEGFR1, VEGFR2, VEGFR3 and PDGFRβ, respectively.

IC50 & Target

IC50: 0.1 nM (VEGFR1), 0.2 nM (VEGFR2), 0.1-0.3 nM (VEGFR3), 1.6 nM (PDGFRβ)[1]

In Vitro

Axitinib (AG-013736) is a potent and selective inhibitor of VEGFR 1 to 3. In transfected or endogenous RTK-expressing cells, Axitinib potently blocks growth factor-stimulated phosphorylation of VEGFR-2 and VEGFR-3 with average IC50 values of 0.2 and 0.1 to 0.3 nM, respectively. Cellular activity against VEGFR-1 is 1.2 nM (measured in the presence of 2.3% bovine serum albumin), equivalent to an absolute IC50 of ~0.1 nM, based on protein binding of Axitinib. The potency against murine VEGFR-2 (Flk-1) in Flk-1-transfected NIH-3T3 cells is 0.18 nM, similar to that of its human homologue. Axitinib shows ~8- to 25-fold higher IC50 against the closely related type III and V family RTKs, including PDGFR-β (1.6 nM), KIT (1.7 nM), and PDGFR-α (5 nM); nanomolar concentrations of Axitinib blocks PDGF BB-mediated human glioma U87MG cell (PDGFR-β-positive) migration but not proliferation[2].

In Vivo

A single oral dose of Axitinib (100 mg/kg) markedly suppresses murine VEGFR-2 phosphorylation for up to 7 h compared with control tumors. Axitinib rapidly inhibits VEGF-induced vascular permeability in the skin of mice; the inhibition is dose-dependent and directly correlated with drug concentration in mice. Pharmacokinetic/pharmacodynamic analysis indicate an unbound EC50 of 0.46 nM. Similar inhibitory effects are also shown in the skin of MV522 tumor-bearing mice without exogenous VEGF-A stimulation. Axitinib inhibits the growth of human xenograft tumors in mice. Axitinib produces dose-dependent growth delay regardless of initial tumor size, model type, or implant site[2].

Clinical Trial
Solvent & Solubility
In Vitro:

DMSO : ≥ 35 mg/mL (90.56 mM)

*"≥" means soluble, but saturation unknown.

Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.5875 mL 12.9376 mL 25.8752 mL
5 mM 0.5175 mL 2.5875 mL 5.1750 mL
10 mM 0.2588 mL 1.2938 mL 2.5875 mL
*Please refer to the solubility information to select the appropriate solvent.
In Vivo:
  • 1.

    Axitinib is prepared in a vehicle formulation of in 0.5% carboxymethylcellulose[3].

Cell Assay

Endothelial or tumor cells are starved for 18 h in the presence of either 1% FBS (HUVEC) or 0.1% FBS (tumor cells). Axitinib is added and cells are incubated for 45 min at 37°C in the presence of 1 mM Na3VO4. The appropriate growth factor is added to the cells, and after 5 min, cells are rinsed with cold PBS and lysed in the lysis buffer and a protease inhibitor cocktail. The lysates are incubated with immunoprecipitation antibodies for the intended proteins overnight at 4°C. Antibody complexes are conjugated to protein A beads and supernatants are separated by SDS-PAGE[2].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Administration

Mice and Rats[2]
Mice with M24met xenograft tumors (400-600 mm3) are administered with a single dose of Axitinib or the control (0.5% carboxymethylcellulose/H2O). Blood and tumor tissue samples are collected for pharmacokinetic and VEGFR-2 measurements. Total protein concentrations in tumor tissues are determined using the Bradford colorimetric assay.
Six-day-old Sprague-Dawley rats are given two i.p. injections of Axitinib (30 mg/kg ). Animals are sacrificed, retinas are collected and lysed, and immunoprecipitation/immunoblotting experiments are done. ECL-Plus is used for detection and densitometry analysis is done using the Alpha Imager 8800.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight








Powder -20°C 3 years
  4°C 2 years
In solvent -80°C 6 months
  -20°C 1 month

Room temperature in continental US; may vary elsewhere

Purity: 99.94%

  • Molarity Calculator

  • Dilution Calculator

The molarity calculator equation

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass   Concentration   Volume   Molecular Weight *
= × ×

The dilution calculator equation

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)
× = ×
C1   V1   C2   V2
