BAM 15

Cat. No.: HY-110284 Purity: 99.97%
Handling Instructions

BAM 15 is a novel mitochondrial protonophore uncoupler.

For research use only. We do not sell to patients.

BAM 15 Chemical Structure

BAM 15 Chemical Structure

CAS No. : 210302-17-3

Size Price Stock Quantity
Free Sample (0.5-1 mg)   Apply now
10 mM * 1 mL in DMSO USD 176 In-stock
Estimated Time of Arrival: December 31
5 mg USD 160 In-stock
Estimated Time of Arrival: December 31
10 mg USD 280 In-stock
Estimated Time of Arrival: December 31
25 mg USD 560 In-stock
Estimated Time of Arrival: December 31
50 mg   Get quote
100 mg   Get quote

* Please select Quantity before adding items.

  • Biological Activity

  • Protocol

  • Technical Information

  • Purity & Documentation

  • References

Description

BAM 15 is a novel mitochondrial protonophore uncoupler.

In Vitro

BAM 15 is able to increase O2 consumption across a broad dosing range without increasing ROS. BAM 15 and FCCP are structurally unrelated and it is observed that low doses of BAM 15 from 100 nM to 1 μM increase cellular O2 consumption rate (OCR) to a similar degree as FCCP, but higher concentrations from 1 μM to 50 μM reveal that BAM 15 is able to maintain uncoupled respiration at a high rate in a range of cell lines. BAM 15 is fully capable of increasing mitochondrial respiration in the presence of oligomycin and does so across a broader concentration range than FCCP in both myoblasts and hepatocytes. BAM 15 induces mitochondrial swelling, demonstrating that BAM 15 is a protonophore. BAM15-treated cells are more viable than FCCP-treated cells when administered across a broad dosing range up to 50 μM[1].

In Vivo

Compare to vehicle-treated mice, animals that receive BAM 15 are protected from kidney injury as indicated by lower plasma creatinine levels at 24 and 48 h post-ischemia, reduced tubular necrosis, less depletion of brush border villi, less obstruction of proximal tubules, and less immune cell infiltration[1].

Solvent & Solubility
In Vitro:

DMSO : 75 mg/mL (220.40 mM; Need ultrasonic)

H2O : < 0.1 mg/mL (insoluble)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.9387 mL 14.6933 mL 29.3867 mL
5 mM 0.5877 mL 2.9387 mL 5.8773 mL
10 mM 0.2939 mL 1.4693 mL 2.9387 mL
*Please refer to the solubility information to select the appropriate solvent.
In Vivo:
  • 1.

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% saline

    Solubility: ≥ 2.5 mg/mL (7.35 mM); Clear solution

References
Kinase Assay
[1]

Electron flow assays are performed. Briefly, 5 μg of mitochondrial protein in MAS is loaded into a 24-well tissue culture plate and centrifuged at 2000×g for 15 min at 4°C. Prior to the assay, mitochondria are incubated at 37°C for 10 mins in MAS containing 10 mM pyruvate, 2 mM malate, and 5 μM BAM 15 or FCCP. Rotenone (2 μM), succinate (10 mM), antimycin A (4 μM), and N,N,N′,N′-tetramethyl-p-phenylenediamine (TMPD, 100 μM) plus ascorbate (10 mM) are added sequentially as indicated in the figure. N=3 wells/plate of a representative of 3 plates[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Cell Assay
[1]

L6 cells are incubated with the fluorescent indicator of mitochondrial membrane potential tetramethylrhodamine (TMRM, 125 nM) or DMSO (1%) control for 30 min. The cells are then centrifuged for 5 min at 700×g and resuspended in unbuffered DMEM at a concentration of 1×105 cells/mL. The cells are then treated with BAM 15 or DMSO (0.1%) for 10 min prior to flow cytometric analysis[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Administration
[1]

Male mice (8-week old, C57BL/6) are anesthetized with a mixture (i.p.) of ketamine (120 mg/kg), xylazine (12 mg/kg), and atropine (0.324 mg/kg) and are subjected to bilateral ischemic reperfusion injury (26 min ischemia, then 24 h or 48 h reperfusion). During the surgery, mouse core temperature is maintained at 34 to 36°C with a heating pad; during the recovery and reperfusion period, mice are housed in a warming incubator with ambient temperature at 30 to 32 °C. Control, sham-operated mice undergo a similar procedure, but the renal pedicles are not clamped. Mice are i.p. injected with BAM 15 at 1 or 5 mg/kg, 1 h before kidney IR. Vehicle mice are also injected with the same solution BAM 15 is prepared with (3% DMSO in 50% PEG400)[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References
Molecular Weight

340.29

Formula

C₁₆H₁₀F₂N₆O

CAS No.

210302-17-3

SMILES

FC(C=CC=C1)=C1NC2=NC3=NON=C3N=C2NC4=C(C=CC=C4)F

Storage
Powder -20°C 3 years
  4°C 2 years
In solvent -80°C 6 months
  -20°C 1 month
Shipping

Room temperature in continental US; may vary elsewhere

  • Molarity Calculator

  • Dilution Calculator

The molarity calculator equation

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass   Concentration   Volume   Molecular Weight *
= × ×

The dilution calculator equation

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)
× = ×
C1   V1   C2   V2
