1. Neuronal Signaling Membrane Transporter/Ion Channel
  2. CaMK P2X Receptor
  3. KN-62

KN-62 is a selective and reversible inhibitor of calmodulin-dependent protein kinase II (CaMK-II) with a Ki of 0.9 μM for rat brain CaMK-II. KN-62 directly binds to the calmodulin binding site of CaMK-II. KN-62 displays noncompetitive antagonism at P2X7 receptors in HEK293 cells, with an IC50 value of approximately 15 nM.

For research use only. We do not sell to patients.

KN-62 Chemical Structure

KN-62 Chemical Structure

CAS No. : 127191-97-3

Size Price Stock Quantity
Solid + Solvent (Highly Recommended)
10 mM * 1 mL in DMSO
ready for reconstitution
USD 140 In-stock
Solution
10 mM * 1 mL in DMSO USD 140 In-stock
Solid
1 mg USD 35 In-stock
5 mg USD 88 In-stock
10 mg USD 150 In-stock
50 mg USD 605 In-stock
100 mg USD 970 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 10 publication(s) in Google Scholar

Top Publications Citing Use of Products

View All CaMK Isoform Specific Products:

View All P2X Receptor Isoform Specific Products:

  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

KN-62 is a selective and reversible inhibitor of calmodulin-dependent protein kinase II (CaMK-II) with a Ki of 0.9 μM for rat brain CaMK-II. KN-62 directly binds to the calmodulin binding site of CaMK-II. KN-62 displays noncompetitive antagonism at P2X7 receptors in HEK293 cells, with an IC50 value of approximately 15 nM.

IC50 & Target[1][2]

P2X7 Receptor



CaMK II

0.9 μM (Ki)

In Vitro

KN-62 potently antagonizes ATP-stimulated Ba2+ influx into fura-2 loaded human lymphocytes with an IC50 of 12.7 nM and complete inhibition of the flux at a concentration of 500 nM[1].
? KN-62 does not inhibit the activity of autophosphorylated Ca2+/CaM kinase II. KN-62 inhibits the Ca2+/calmodulin-dependent autophosphorylation of both alpha (50 kDa) and beta (60 kDa) subunits of Ca2+/CaM kinase II dose dependently in the presence or absence of exogenous substrate[2].
? In human leukemic B lymphocytes, KN-62 reduces the rate of permeability increase to larger permeant cations, like ethidium, induced by Bz-ATP with an IC50 of 13.1 nM[4].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

KN62 (5?mg/kg/day; ip; three times a week for 6 weeks) significantly reduces the liver metastatic tumor burden in five weeks old BALB/c athymic nude mice inoculated with TAMR-MCF-7 cells[3].
? KN-62 (1 μg/site, i.c.v.) prevents the antidepressant-like behavior and antidepressant-like behaviors of ZnCl2 (10 mg/kg, p.o.)[5].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

721.84

Formula

C38H35N5O6S2

CAS No.
Appearance

Solid

Color

Light yellow to yellow

SMILES

O=C(N1CCN(C2=CC=CC=C2)CC1)[C@H](CC3=CC=C(C=C3)OS(=O)(C4=CC=CC5=C4C=CN=C5)=O)N(C)S(=O)(C6=CC=CC7=C6C=CN=C7)=O

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 1 year
-20°C 6 months
Solvent & Solubility
In Vitro:

DMSO : ≥ 100 mg/mL (138.53 mM; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

*"≥" means soluble, but saturation unknown.

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 1.3853 mL 6.9267 mL 13.8535 mL
5 mM 0.2771 mL 1.3853 mL 2.7707 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 1 year; -20°C, 6 months. When stored at -80°C, please use it within 1 year. When stored at -20°C, please use it within 6 months.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 2.5 mg/mL (3.46 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% Corn Oil

    Solubility: ≥ 2.5 mg/mL (3.46 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown). If the continuous dosing period exceeds half a month, please choose this protocol carefully.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL Corn oil, and mix evenly.

In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.45%

References
Kinase Assay
[1]

Lymphocytes (1×107/mL) are cultured with [3H]-oleic acid (2-5 μCi/mL, specific activity 10 Ci/mmol) for 20-24 h in RPMI-1640 medium supplemented with Gentamicin (40 μg/mL), 10% heat inactivated foetal calf serum (FCS) at 37°C to label membrane phospholipids. Labelled cells are washed twice in HEPES buffered saline followed by a final wash in either HEPES buffered saline or 150 mM KCl medium containing HEPES 10 mM, pH 7.4, bovine serum albumin (BSA) 1 g/L and D-glucose 5 mM and CaCl2 1 mM. Three mL aliquots containing 1.1×10< sup>7/mL lymphocytes are warmed to 37°C and incubated with or without KN-62 or KN-04 (1 nM-500 nM) for 5 min, then 900 mL aliquots are added to 100 uL butanol (final concentration 30 mM) for a further 5 min, and stimulated with 1 mM ATP for 15 min with gentle mixing in the continued presence of inhibitor or diluent. The phospholipase D reaction is terminated by addition of 1 mL of 20 mM MgCl2 followed by centrifugation and addition of 1 mL ice cold methanol. Membrane lipids are extracted into chloroform/HCl at 4°C under N2, and separated by silica gel thin layer chromatography (t.l.c.) with the solvent system, ethyl acetate/iso-octane/acetic acid/water (13:2:3:10, v/v) under saturating conditions. Sample spots are located by autoradiography and [3H]-phosphatidylbutanol ([3H]-PBut) spots identified by an authentic standard. [3H]-PBut and [3H]-phospholipid spots are scraped into scintillant fluid (PPO in toluene, 4 g/L) and counted in a liquid scintillation counter. The quantity of [3H]-PBut is presented as a percentage of total 3H labelled-cellular phospholipids. Phospholipase D assays are performed in triplicate[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Cell Assay
[4]

All experiments are performed using adherent HEK293 cells stably transfected with cDNA encoding the human P2X7 receptor. Adherent cells on 12-well polylysine-coated plates are incubated at 37°C in 1 mL physiological salt solution (125 mM NaCl, 5 mM KCl, 1 mM MgCl2, 1.5 mM CaCl2, 25 mM NaHEPES (pH 7.5), 10 mM D-glucose, 1 mg/mL BSA). Antagonists(e.g., KN-62) are added from 1,000× stock solutions dissolved in DMSO. Cells are preincubated with antagonists (e.g., KN-62) for 15 min prior to stimulation for 10 min with 3 mM ATP (final concentration). Reactions are terminated by rapid aspiration of the extracellular medium in each well. The adherent cells in each well are then extracted overnight with 1 mL 10% HNO3. K+ content in these nitric acid extracts is assayed by atomic absorbance spectrophotometry. Duplicate or triplicate wells are run for all test conditions in each separate experiment[4].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Administration
[5]

Mice[3]
Female Swiss mice (45-55 days old, weighing 30-45 g) are used. The following drugs are used: ZnCl2 (1 or 10 mg/kg), H-89 (1 μg/site, PKA inhibitor), KN-62 (1 μg/site, CAMKII inhibitor), chelerythrine (1 μg/site, PKC inhibitor), PD98059 (5 μg/site, MAPKK/MEK 1/2 inhibitor), U0126 (5 μg/site, MEK1/2 inhibitor), LY294002 (10 nmol/site, PI3K inhibitor), AR-A014418 (0.001 μg/site, selective GSK-3β inhibitor). ZnCl2 is dissolved in distilled water and administered orally (p.o.). H-89, KN-62, chelerythrine, PD98059, U0126, LY294002, AR-A014418 are dissolved in saline (0.9% NaCl) at a final concentration of 1% dimethyl sulfoxide (DMSO) and administered by intracerebroventricular (i.c.v.) route. The drugs are freshly prepared before treatment and administered in a volume of 10 mL/kg body weight (p.o. route) or 5 μL/site (i.c.v. route). Control animals receive the appropriate vehicle.

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 1 year; -20°C, 6 months. When stored at -80°C, please use it within 1 year. When stored at -20°C, please use it within 6 months.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 1.3853 mL 6.9267 mL 13.8535 mL 34.6337 mL
5 mM 0.2771 mL 1.3853 mL 2.7707 mL 6.9267 mL
10 mM 0.1385 mL 0.6927 mL 1.3853 mL 3.4634 mL
15 mM 0.0924 mL 0.4618 mL 0.9236 mL 2.3089 mL
20 mM 0.0693 mL 0.3463 mL 0.6927 mL 1.7317 mL
25 mM 0.0554 mL 0.2771 mL 0.5541 mL 1.3853 mL
30 mM 0.0462 mL 0.2309 mL 0.4618 mL 1.1545 mL
40 mM 0.0346 mL 0.1732 mL 0.3463 mL 0.8658 mL
50 mM 0.0277 mL 0.1385 mL 0.2771 mL 0.6927 mL
60 mM 0.0231 mL 0.1154 mL 0.2309 mL 0.5772 mL
80 mM 0.0173 mL 0.0866 mL 0.1732 mL 0.4329 mL
100 mM 0.0139 mL 0.0693 mL 0.1385 mL 0.3463 mL
