1. Cell Cycle/DNA Damage
  2. DNA/RNA Synthesis
  3. ML216

ML216 (CID-49852229) is a potent, selective and cell permeable inhibitor of the DNA unwinding activity of BLM helicase with IC50s of 2.98 μM and 0.97 μM for BLMfull-length and BLM636-1298, respectively. ML216 inhibits ssDNA-dependent ATPase activity of BLM with a Ki of 1.76 µM. Antitumor avtivity.

For research use only. We do not sell to patients.

ML216 Chemical Structure

ML216 Chemical Structure

CAS No. : 1430213-30-1

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 80 In-stock
Solution
10 mM * 1 mL in DMSO USD 80 In-stock
Solid
5 mg USD 73 In-stock
10 mg USD 105 In-stock
50 mg USD 230 In-stock
100 mg USD 330 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 5 publication(s) in Google Scholar

Top Publications Citing Use of Products
  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

ML216 (CID-49852229) is a potent, selective and cell permeable inhibitor of the DNA unwinding activity of BLM helicase with IC50s of 2.98 μM and 0.97 μM for BLMfull-length and BLM636-1298, respectively. ML216 inhibits ssDNA-dependent ATPase activity of BLM with a Ki of 1.76 µM. Antitumor avtivity[1][2].

IC50 & Target

IC50: 2.98 μM (BLMfull-length) and 0.97 μM (BLM636-1298)[1]

In Vitro

ML216 (12.5-50 μM; 24-72 hours; PSNG5 and PSNG13cells) treatment inhibits the proliferation of PSNF5 cells in a concentration-dependent manner, but not of PSNG13 cells[1].
? ML216 treatment leads to a statistically significant increase in the frequency of sister chromatid exchanges (SCEs) in PSNF5 cells, but not in PSNG13 cells[1].
? ML216 increases the sensitivity of PSNF5 cells to aphidicolin but has no sensitizing effect on isogenic PSNG13 cells devoid of BLM[1].
? ML216 inhibits both the full length WRN (IC50 of 5 μM) and a truncated WRN500-946 (IC50 of 12.6 μM), with the former being 2.5-fold more sensitive to inhibition. BLM is a little more sensitive than WRN to inhibition by ML216 (1.7-fold based on IC50 values). Despite the detectable inhibition of WRN by ML216, this compound appears selective for BLM in human cells. ML216 inhibits proliferation of WRN+ and WRN? cells equally well, and similarly sensitized both cell types to aphidicolin[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Cell Proliferation Assay[1]

Cell Line: PSNG5 and PSNG13cells
Concentration: 12.5 μM or 50 µM
Incubation Time: 24 hours, 48 hours, 72 hours
Result: Inhibited the proliferation of PSNF5 cells, but not of PSNG13 cells, and did so in a concentration-dependent manner.
In Vivo

Although ML216 inhibits unwinding by the sequence-related BLM and WRN helicases similarly in vitro, the apparent dependence on BLM for ML216 to exert its biological effects in human cells suggests BLM specificity for the drug’s mechanism of action in vivo. A co-crystal structure of BLM in complex with inhibitor would be informative. Cellular cues in vivo may induce a specific conformation of WRN that makes it resistant to ML216[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

383.32

Formula

C15H9F4N5OS

CAS No.
Appearance

Solid

Color

Light yellow to yellow

SMILES

O=C(NC1=CC=C(F)C(C(F)(F)F)=C1)NC2=NN=C(S2)C3=CC=NC=C3

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 2 years
-20°C 1 year
Solvent & Solubility
In Vitro:

DMSO : 20 mg/mL (52.18 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.6088 mL 13.0439 mL 26.0879 mL
5 mM 0.5218 mL 2.6088 mL 5.2176 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: 2 mg/mL (5.22 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (20.0 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.89%

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 2.6088 mL 13.0439 mL 26.0879 mL 65.2197 mL
5 mM 0.5218 mL 2.6088 mL 5.2176 mL 13.0439 mL
10 mM 0.2609 mL 1.3044 mL 2.6088 mL 6.5220 mL
15 mM 0.1739 mL 0.8696 mL 1.7392 mL 4.3480 mL
20 mM 0.1304 mL 0.6522 mL 1.3044 mL 3.2610 mL
25 mM 0.1044 mL 0.5218 mL 1.0435 mL 2.6088 mL
30 mM 0.0870 mL 0.4348 mL 0.8696 mL 2.1740 mL
40 mM 0.0652 mL 0.3261 mL 0.6522 mL 1.6305 mL
50 mM 0.0522 mL 0.2609 mL 0.5218 mL 1.3044 mL
