E7820 (ER68203-00), an orally active aromatic sulfonamide derivative, is a unique angiogenesis inhibitor suppressing an expression of integrin alpha2 subunit on endothelium. E7820 inhibits rat aorta angiogenesis with an IC50 of 0.11 μg/ml. E7820 modulates α-1, α-2, α-3, and α-5 integrin mRNA expression. Antiangiogenic and antitumor activity.

For research use only. We do not sell to patients.

E7820 Chemical Structure

E7820 Chemical Structure

CAS No. : 289483-69-8

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
USD 97 In-stock
Solution
10 mM * 1 mL in DMSO USD 97 In-stock
Solid
5 mg USD 88 In-stock
10 mg USD 100 In-stock
25 mg USD 180 In-stock
50 mg USD 270 In-stock
100 mg USD 432 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 3 publication(s) in Google Scholar

Top Publications Citing Use of Products
  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

E7820 (ER68203-00), an orally active aromatic sulfonamide derivative, is a unique angiogenesis inhibitor suppressing an expression of integrin alpha2 subunit on endothelium. E7820 inhibits rat aorta angiogenesis with an IC50 of 0.11 μg/ml. E7820 modulates α-1, α-2, α-3, and α-5 integrin mRNA expression. Antiangiogenic and antitumor activity[1][2].

In Vitro

E7820 (ER68203-00) inhibits both bFGF- and VEGF-driven ube formation of human umbilical vascular endothelial cell (HUVEC) in a dose-dependent manner with IC50 of 0.20 and 0.24 μg/ml, respectively[1].
? E7820 inhibits proliferation of HUVEC induced by either bFGF or VEGF in serum-free medium (SFM). The IC50 values are 0.10 and 0.081 μg/ml, respectively. Antiproliferative activity of E7820 against both WiDr and LoVo cells is very weak compared with that against HUVEC. The values of IC50 were 29 and 15 μg/ml, respectively[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

E7820 (ER68203-00) (50-200 mg/kg; p.o. ; twice daily for 14 days) delays the growth of WiDr cells inoculated s.c.[1].
E7820 (200-400 mg/kg; p.o.;once daily for 4 days) potently inhibits WiDr-induced angiogenesis[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Model: Six-week-old female nude mice (KSN mice, WiDr-induced angiogenesis model) [1]
Dosage: 50, 100, 200 mg/kg
Administration: p.o. ; twice daily for 14 days from 2 days after inoculation of the tumor cells
Result: The antitumor effect was dose-dependent at 50, 100, and 200 mg/kg, and the tumor growth rates were 52%, 46%, and 27%, respectively.
Clinical Trial
Molecular Weight

336.37

Formula

C17H12N4O2S

CAS No.
Appearance

Solid

Color

Light yellow to brown

SMILES

O=S(C1=CC(C#N)=CC=C1)(NC2=C(NC=C3C#N)C3=C(C)C=C2)=O

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 6 months
-20°C 1 month
Solvent & Solubility
In Vitro:

DMSO : 100 mg/mL (297.29 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.9729 mL 14.8646 mL 29.7292 mL
5 mM 0.5946 mL 2.9729 mL 5.9458 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: ≥ 2.5 mg/mL (7.43 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% Corn Oil

    Solubility: ≥ 2.5 mg/mL (7.43 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown). If the continuous dosing period exceeds half a month, please choose this protocol carefully.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL Corn oil, and mix evenly.

In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.25%

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 2.9729 mL 14.8646 mL 29.7292 mL 74.3229 mL
5 mM 0.5946 mL 2.9729 mL 5.9458 mL 14.8646 mL
10 mM 0.2973 mL 1.4865 mL 2.9729 mL 7.4323 mL
15 mM 0.1982 mL 0.9910 mL 1.9819 mL 4.9549 mL
20 mM 0.1486 mL 0.7432 mL 1.4865 mL 3.7161 mL
25 mM 0.1189 mL 0.5946 mL 1.1892 mL 2.9729 mL
30 mM 0.0991 mL 0.4955 mL 0.9910 mL 2.4774 mL
40 mM 0.0743 mL 0.3716 mL 0.7432 mL 1.8581 mL
50 mM 0.0595 mL 0.2973 mL 0.5946 mL 1.4865 mL
60 mM 0.0495 mL 0.2477 mL 0.4955 mL 1.2387 mL
80 mM 0.0372 mL 0.1858 mL 0.3716 mL 0.9290 mL
100 mM 0.0297 mL 0.1486 mL 0.2973 mL 0.7432 mL
