  4. DT2216

DT2216 is a potent and selective BCL-XL (Bcl-2 family member) degrader based on PROTAC technology. DT2216 causes effective degradation of BCL-XL protein by recruiting Von Hippel-Lindau (VHL) E3 ubiquitin ligase. DT2216 inhibits various BCL-XL-dependent leukemia and cancer cells but considerably less toxic to platelets. DT2216 is composed of the Bcl-2 family protein inhibitor Navitoclax (HY-10087), a linker, and a VHL E3 ubiquitin ligase (Red: Navitoclax; Blue: VHL ligand; Black: linker).

For research use only. We do not sell to patients.

DT2216 Chemical Structure

DT2216 Chemical Structure

CAS No. : 2365172-42-3

Size Price Stock Quantity
5 mg USD 350 In-stock
10 mg USD 560 In-stock
25 mg USD 1120 In-stock
50 mg USD 1790 In-stock
100 mg USD 2900 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 1 publication(s) in Google Scholar

DT2216 Related Antibodies

Top Publications Citing Use of Products

1 Publications Citing Use of MCE DT2216

View All Bcl-2 Family Isoform Specific Products:

View All Isoforms

View All PROTACs Isoform Specific Products:

View All Isoforms

  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

DT2216 is a potent and selective BCL-XL (Bcl-2 family member) degrader based on PROTAC technology. DT2216 causes effective degradation of BCL-XL protein by recruiting Von Hippel-Lindau (VHL) E3 ubiquitin ligase. DT2216 inhibits various BCL-XL-dependent leukemia and cancer cells but considerably less toxic to platelets. DT2216 is composed of the Bcl-2 family protein inhibitor Navitoclax (HY-10087), a linker, and a VHL E3 ubiquitin ligase (Red: Navitoclax; Blue: VHL ligand; Black: linker)[1].

IC50 & Target[1]

VHL



In Vitro

DT2216 (62.5, 125 nM; 72 hours) kills MOLT-4 cells[1].
DT2216 (0.001-10 μM; 72 hour) shows highly toxic to MOLT-4 cells with an EC50 of 0.052 μM[1].
DT2216 (0.1, 0.3 μM; 24 hours) kills MOLT-4 cells by caspase-3-mediated induction of apoptosis in a BCL-2 homologous antagonist killer (BAK)- and BCL-2-associated X protein (BAX)-dependent manner[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

DT2216 Related Antibodies

Apoptosis Analysis[1]

Cell Line: MOLT-4 cells
Concentration: 62.5, 125 nM
Incubation Time: 72 hours
Result: Killed MOLT-4 cells.

Cell Cytotoxicity Assay[1]

Cell Line: MOLT-4 cells
Concentration: 0.001, 0.01, 0.1, 1, 10 μM
Incubation Time: 72 hours
Result: Showed highly toxic to MOLT-4 cells with an EC50 of 0.052 μM.

Western Blot Analysis[1]

Cell Line: MOLT-4 cells
Concentration: 0.1, 0.3 μM
Incubation Time: 24 hours
Result: Killed MOLT-4 cells by caspase-3-mediated induction of apoptosis in a BCL-2 homologous antagonist killer (BAK)- and BCL-2-associated X protein (BAX)-dependent manner.
In Vivo

DT2216 (i.p.; 7.5, 15 mg/kg; weekly for 60 days) of 15 mg/kg is more effective at suppressing the growth of MOLT-4 T-ALL xenografts in mice than 7.5 mg/kg[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Animal Model: CB17/Icr-Prkdcscid/IcrIcoCrl (CB-17 SCID) mice aged 5-6 weeks[1]
Dosage: 7.5, 15 mg/kg
Administration: i.p.; weekly for 60 days
Result: Suppressed the growth of MOLT-4 T-ALL xenografts in mice.
Molecular Weight

1542.36

Formula

C77H96ClF3N10O10S4
CAS No.
Appearance

Solid

Color

White to light yellow

SMILES

CC1(C)CCC(C2=CC=C(Cl)C=C2)=C(C1)CN3CCN(C4=CC=C(C(NS(=O)(C5=CC(S(C(F)(F)F)(=O)=O)=C(N[C@@H](CSC6=CC=CC=C6)CCN7CCN(C(CCCCCC(N[C@@H](C(C)(C)C)C(N8[C@@H](C[C@@H](O)C8)C(N[C@H](C9=CC=C(C%10=C(N=CS%10)C)C=C9)C)=O)=O)=O)=O)CC7)C=C5)=O)=O)C=C4)CC3
Shipping

Room temperature in continental US; may vary elsewhere.
Storage

-20°C, stored under nitrogen

*In solvent : -80°C, 6 months; -20°C, 1 month (stored under nitrogen)

Solvent & Solubility
In Vitro:

DMSO : 25 mg/mL (16.21 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 0.6484 mL 3.2418 mL 6.4836 mL
5 mM 0.1297 mL 0.6484 mL 1.2967 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month (stored under nitrogen). When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: 2.5 mg/mL (1.62 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2.5 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: 2.5 mg/mL (1.62 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2.5 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
%
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).

*In solvent : -80°C, 6 months; -20°C, 1 month (stored under nitrogen)

The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.97%

COA (246 KB) HNMR (266 KB) RP-HPLC (247 KB)

Handling Instructions (2659 KB)
References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month (stored under nitrogen). When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 0.6484 mL 3.2418 mL 6.4836 mL 16.2089 mL
5 mM 0.1297 mL 0.6484 mL 1.2967 mL 3.2418 mL
10 mM 0.0648 mL 0.3242 mL 0.6484 mL 1.6209 mL
15 mM 0.0432 mL 0.2161 mL 0.4322 mL 1.0806 mL
