1. Epigenetics
  2. Histone Methyltransferase

AZ505 ditrifluoroacetate (Synonyms: AZ 505 ditrifluoroacetate; AZ-505 ditrifluoroacetate)

Cat. No.: HY-15226A Purity: 99.99%
Handling Instructions

AZ505 ditrifluoroacetate is a potent and selective SMYD2 inhibitor with IC50 of 0.12 μM.

For research use only. We do not sell to patients.
AZ505 ditrifluoroacetate Chemical Structure

AZ505 ditrifluoroacetate Chemical Structure

CAS No. : 1035227-44-1

Size Price Stock Quantity
10 mM * 1 mL in DMSO USD 340 In-stock
5 mg USD 228 In-stock
10 mg USD 384 In-stock
25 mg USD 816 In-stock
50 mg USD 1188 In-stock
100 mg USD 1800 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

Other Forms of AZ505 ditrifluoroacetate:

    AZ505 ditrifluoroacetate purchased from MCE. Usage Cited in: J Clin Invest. 2017 Jun 30;127(7):2751-2764.

    PKD-associated signaling pathways can be affected by SMYD2 in Pkd1 mutant renal epithelial cells and cystic tissues. Western blot analysis of the phosphorylation of ERK, S6, AKT, and Rb as well as the total protein levels of these proteins in Pkd1-null MEK cells with or without AZ505 treatment for 2 hours.

    AZ505 ditrifluoroacetate purchased from MCE. Usage Cited in: Cell Death Dis. 2018 Feb 27;9(3):326.

    Inhibition of SMYD2 with AZ505 (40 μM, 2 h) decreases the methylation and phosphorylation of STAT3 and p65, but dpes not affect their expression in MDA-MB231 cells.
    • Biological Activity

    • Protocol

    • Technical Information

    • Purity & Documentation

    • References


    AZ505 ditrifluoroacetate is a potent and selective SMYD2 inhibitor with IC50 of 0.12 μM.

    IC50 & Target

    IC50: 0.12 μM (SMYD2)[1]

    In Vitro

    AZ505 ditrifluoroacetate is highly selective and shows an activity at submicromolar concentrations in vitro. The IC50 of AZ505 for SMYD2 is 0.12 μM, which is >600-fold greater than the IC50s of AZ505 for other histone methyltransferases, such as SMYD3 (IC50>83.3 μM), DOT1L (IC50>83.3 μM) and EZH2 (IC50>83.3 μM)[1]. AZ505 is a potent and selective SMYD2 inhibitor with an IC50 of 0.12 μM. The human SMYD (SET and MYND domain-containing protein) family of protein lysine methyltransferases contains five members (SMYD1-5). Moreover, AZ505 fails to inhibit the enzymatic activities of a panel of protein lysine methyltransferases. AZ505 is nominated for ITC binding study with Kd of 0.5 μM. In contrast, the calculated Kd for the p53 substrate peptide is 3.7 μM. AZ505 binding to SMYD2 is driven primarily by entropy, which often suggests that binding is mediated by hydrophobic interactions with few specific hydrogen bonds[2].

    Preparing Stock Solutions
    Concentration Volume Mass 1 mg 5 mg 10 mg
    1 mM 1.2413 mL 6.2066 mL 12.4133 mL
    5 mM 0.2483 mL 1.2413 mL 2.4827 mL
    10 mM 0.1241 mL 0.6207 mL 1.2413 mL
    Please refer to the solubility information to select the appropriate solvent.
    Kinase Assay

    SMYD2 is expressed in insect cells and purified. AlphaScreen technology is used to screen our chemical library for small molecule inhibitors of SMYD2. Methylation (12 μL) reactions are carried out in TDT buffer (50 mM Tris-HCl [pH 9.0], 2 mM DTT, and 0.01% Tween 20) at room temperature using 1.25 nM SMYD2 protein, 200 nM SAM, and 100 nM biotinylated p53 peptide substrate (Biotin-aminohexanoyl-GSRAHSSHLKSKKGQSTSRH) in low volume 384-well plates. Following a 75 min incubation period, reactions are quenched by the addition of 5 μL of detection solution (20 mM HEPES [pH 7.4], 1.7 mg/mL BSA, 340 mM NaCl, 680 μM SAH, 0.04 mg/mL Streptavidin-coated AlphaScreen donor, and Protein A-coated acceptor beads), and 1 nM of a custom p53K370me1 polyclonal antibody. Reaction plates are incubated overnight in the dark at room temperature, and read using an Envision 2101 Multi-label Reader. Compounds showing >50% inhibition of SMYD2 are nominated for concentration dose-response determination, and are also subjected to an artifact assay. Seven compound concentrations are selected beginning at 30 μM with six half-log dilution steps. The artifact assay conditions are identical to those in the SMYD2 enzymatic activity assay, except for the absence of SMYD2 protein and the presence of 1 nM methylated p53 peptide. IC50 values are calculated from dose-response data using in-house software[2]. MCE has not independently confirmed the accuracy of these methods. They are for reference only.

    Molecular Weight




    CAS No.




    Powder -20°C 3 years
      4°C 2 years
    In solvent -80°C 6 months
      -20°C 1 month

    Room temperature in continental US; may vary elsewhere

    Solvent & Solubility

    DMSO: ≥ 42 mg/mL

    * "<1 mg/mL" means slightly soluble or insoluble. "≥" means soluble, but saturation unknown.
