BODIPY 493/503 (Synonyms: Pyrromethene 546; BDP 493/503 lipid stain)

Cat. No.: HY-W090090
Handling Instructions

BODIPY 493/503 (Pyrromethene 546) is a fluorescent neutral lipid dye (Ex/Em: 493/503 nm). BODIPY 493/503 can facilitate quantification of neutral lipid content by flow cytometry and observation of lipid droplets (LDs) by microscopy.

For research use only. We do not sell to patients.

BODIPY 493/503 Chemical Structure

BODIPY 493/503 Chemical Structure

CAS No. : 121207-31-6

Size Stock
100 mg   Get quote
250 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

Top Publications Citing Use of Products
  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

BODIPY 493/503 (Pyrromethene 546) is a fluorescent neutral lipid dye (Ex/Em: 493/503 nm). BODIPY 493/503 can facilitate quantification of neutral lipid content by flow cytometry and observation of lipid droplets (LDs) by microscopy[1].

In Vitro

Guidelines (Following is our recommended protocol. This protocol only provides a guideline, and should be modified according to your specific needs).
A. BODIY staining for flow cytometry
1. Grow cells under culture conditions relevant for the study.
2. At the time-point of interest, prepare 2 μM BODIPY staining solution in PBS. The volume of staining solution required for each sample corresponds to the volume of media used for culturing cells.
3. Wash cells with a quick rinse using 3 mL PBS to remove media/serum.
4. Incubate on BODIPY staining solution in the dark for 15 min at 37°C. Include an unstained control for flow cytometry. (Note: From this point, protect samples from light as much as possible)
5. Wash cells with a quick rinse using 3 mL PBS to remove staining solution.
6. Trypsinize cells to generate a single cell suspension.
7. Add 5 mL of PBS and transfer cell suspension to a 15 mL conical tube.
8. Pellet cells at 250×g, 5 min, 4 °C.
9. Aspirate supernatant, wash the cell pellet with a quick rinse using 3 mL PBS, and pellet cells at 250×g, 5 min, 4°C.
10. Carefully aspirate the supernatant and resuspend cells in 300 μL 1×flow cytometry buffer.
11. Pass cell suspension through a 35 μM filter into a FACS tube.
12. Perform flow cytometry. Obtain a minimum of 10,000 events per condition.
13. The investigator can analyze data as mean fluorescence or display the data as a histogram[1].
B. BODIY staining for microscopy
1. Autoclave coverslips in a glass bottle.
2. In the tissue culture hood, place coverslips into 35 mm cell culture dishes.
3. Prepare 2 mg/mL collagen solution in PBS.
4. Treat the coverslips with collagen to promote cell adherence. Add 3 mL collagen solution to culture dishes and incubate at 37°C for 30 min. Note: Use forceps to ensure that coverslips are flush with the bottom of the culture dish, eliminating any air bubbles that may be under the cover slips.
5. Aspirate the collagen solution.
6. Wash with PBS.
7. Add PBS to culture dishes and place under UV light in the culture hood to sterilize.
8. Plate cells into culture dishes containing the coverslips. The optimal cell number should be determined to achieve confluence of 30-50% at the time of staining to permit proper imaging.
9. Incubate under the culture conditions relevant to your experiment.
10. At the time-point of interest, prepare 2 μM BODIPY staining solution in PBS.
11. Wash cells with 3 mL PBS.
12. Incubate on 3 mL staining solution for 15 min at 37 °C. (Note: From this point, protect samples from light as much as possible)
13. Wash twice in 3 mL PBS.
14. Fix cells in 3 mL 4% PFA for 30 min at room temperature.
15. Remove 4% PFA.
16. Wash samples 3×5 min in PBS.
17. Use forceps to mount cover slips onto glass slides.
18. Allow the mounting solution to cure overnight at room temperature.
19. Slides can be stored at 4°C or imaged immediately[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

262.11

Formula

C14H17BF2N2

CAS No.
SMILES

[F-][B+3]1([N]2=C(C)C=C(C)C2=C(C)C3=C(C)C=C(C)[N-]31)[F-]

Shipping

Room temperature in continental US; may vary elsewhere.

Storage

4°C, sealed storage, away from moisture

*In solvent : -80°C, 6 months; -20°C, 1 month (sealed storage, away from moisture)

Purity & Documentation
References
  • No file chosen (Maximum size is: 1024 Kb)
  • If you have published this work, please enter the PubMed ID.
  • Your name will appear on the site.
  • Molarity Calculator

  • Dilution Calculator

The molarity calculator equation

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass   Concentration   Volume   Molecular Weight *
= × ×

The dilution calculator equation

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)
× = ×
C1   V1   C2   V2
