ML240 is a potent p97 inhibitor, inhibiting p97 ATPase with IC50 value of 100 nM.

For research use only. We do not sell to patients.

ML240 Chemical Structure

ML240 Chemical Structure

CAS No. : 1346527-98-7

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent (Highly Recommended)
10 mM * 1 mL in DMSO
ready for reconstitution
USD 101 In-stock
Solution
10 mM * 1 mL in DMSO USD 101 In-stock
Solid
5 mg USD 92 In-stock
10 mg USD 145 In-stock
25 mg USD 304 In-stock
50 mg USD 528 In-stock
100 mg USD 924 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 3 publication(s) in Google Scholar

Top Publications Citing Use of Products
  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

ML240 is a potent p97 inhibitor, inhibiting p97 ATPase with IC50 value of 100 nM.

IC50 & Target

IC50: 100 nM (p97)[1]

In Vitro

ML240 is a potent p97 inhibitor, with an IC50 of 100 nM. ML240 is active in the UbG76V-GFP stabilization assay (IC50, 0.9 μM). ML240 inhibits p97 competitively with respect to ATP with a Ki values of 0.22 μM. ML240 also inhibits labeling of only three protein kinase domains by >50% when tested at 20 μM: PIP5 K3 (belongs to phosphoinositide-3 kinase family), JAK1 JH2 (N-terminal pseudokinase domain of JAK1), and DNAPK (DNA-dependent protein kinase). ML240 (1.1, 3.3, 10, or 20 μM) induces executioner caspases 3 and 7 and triggers cell death independently of apical caspases 8 and 9[1]. ML240 is cytotoxic to HCT15 and SW403 cells, with GI50s of 0.76 and 0.5 μM after treatment for 24 h, and 0.54 and 0.5 μM after treatment for 72 h, respectively[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Molecular Weight

396.44

Formula

C23H20N6O

CAS No.
Appearance

Solid

Color

Light yellow to yellow

SMILES

COC1=CC=CC2=C(NCC3=CC=CC=C3)N=C(N4C(N)=NC5=CC=CC=C45)N=C12

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 2 years
-20°C 1 year
Solvent & Solubility
In Vitro:

DMSO : 12.5 mg/mL (31.53 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Ethanol : < 1 mg/mL (insoluble)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.5224 mL 12.6122 mL 25.2245 mL
5 mM 0.5045 mL 2.5224 mL 5.0449 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: 2.5 mg/mL (6.31 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2.5 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: 2.5 mg/mL (6.31 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2.5 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation
References
Cell Assay
[2]

HeLa cells stably expressing ODD-luciferase are seeded onto a 96-well white solid bottom plate (5000 cells/well) and cells are grown for 16 h. Cells are treated with DMEM containing MG132 (4 μM) for 1h and washed with 100 μL PBS twice. DMEM containing 2.5% FBS, cycloheximide (50 μg/mL) and ML240 are added into the well. Four 96-well plates are prepared and one of the plates is taken out from incubator at each time point (70, 90, 120, or 150 min). Luciferin (50 μL of 1 mg/mL in PBS) is added into each well containing 50 μL of medium and incubated at room temperature with shaking at 500 rpm for 5 min. Luminescence intensity is determined with 0.1 ms integration time on the Synergy HT Microplate Reader[2].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year. When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 2.5224 mL 12.6122 mL 25.2245 mL 63.0612 mL
5 mM 0.5045 mL 2.5224 mL 5.0449 mL 12.6122 mL
10 mM 0.2522 mL 1.2612 mL 2.5224 mL 6.3061 mL
15 mM 0.1682 mL 0.8408 mL 1.6816 mL 4.2041 mL
20 mM 0.1261 mL 0.6306 mL 1.2612 mL 3.1531 mL
25 mM 0.1009 mL 0.5045 mL 1.0090 mL 2.5224 mL
30 mM 0.0841 mL 0.4204 mL 0.8408 mL 2.1020 mL
