1. Immunology/Inflammation
  2. Galectin
  3. OTX008

OTX008  (Synonyms: Calixarene 0118; PTX008)

Cat. No.: HY-19756 Purity: 99.09%
COA Handling Instructions

OTX008 is a selective inhibitor of galectin-1.

For research use only. We do not sell to patients.

OTX008 Chemical Structure

OTX008 Chemical Structure

CAS No. : 286936-40-1

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
5 mg USD 190 In-stock
10 mg USD 290 In-stock
25 mg USD 590 In-stock
50 mg   Get quote
100 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 8 publication(s) in Google Scholar

Top Publications Citing Use of Products

View All Galectin Isoform Specific Products:

  • Biological Activity

  • Protocol

  • Purity & Documentation

  • References

  • Customer Review

Description

OTX008 is a selective inhibitor of galectin-1.

IC50 & Target

Galectin-1



In Vitro

Growth inhibitory concentrations (GI50) of OTX008 in a large panel of human solid tumour cell lines ranges from 3 to 500 μM. A significant correlation between OTX008 GI50 values and Gal1 mRNA (LGALS1) and protein expression levels in the panel of cancer cells is observed. In SQ20B and A2780-1A9 cells, OTX008 inhibits Gal1 expression and ERK1/2 and AKT-dependent survival pathways, and induces G2/M cell cycle arrest through CDK1. OTX008 enhances the anti-proliferative effects of Semaphorin-3A (Sema3A) in SQ20B cells and reverses invasion induced by exogenous Gal1[1]. OTX008 affects endothelial cell proliferation, motility, invasiveness, and cord formation. Tumor cell proliferation is also inhibited, with differences in sensitivity among cell lines (IC50 from 1 to 190 μM)[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

In Vivo

OTX008 inhibits growth of A2780-1A9 xenografts. OTX008 treatment is associated with down-regulation of Gal1 and Ki67 in treated tumours, as well as decreased microvessel density and VEGFR2 expression. Finally, combination studies show OTX008 synergy with several cytotoxic and targeted therapies, principally when OTX008 is administered first[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

Clinical Trial
Molecular Weight

937.18

Formula

C52H72N8O8

CAS No.
Appearance

Solid

Color

White to off-white

SMILES

O=C(NCCN(C)C)COC1=C(C2)C=CC=C1CC3=C(OCC(NCCN(C)C)=O)C(CC4=CC=CC(CC5=CC=CC2=C5OCC(NCCN(C)C)=O)=C4OCC(NCCN(C)C)=O)=CC=C3

Shipping

Room temperature in continental US; may vary elsewhere.

Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 6 months
-20°C 1 month
Solvent & Solubility
In Vitro:

Ethanol : 33.33 mg/mL (35.56 mM; Need ultrasonic)

DMSO : 5 mg/mL (5.34 mM; ultrasonic and warming and heat to 60°C; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 1.0670 mL 5.3352 mL 10.6703 mL
5 mM 0.2134 mL 1.0670 mL 2.1341 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% EtOH    90% Saline

    Solubility: ≥ 1.25 mg/mL (1.33 mM); Clear solution

  • Protocol 2

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 0.5 mg/mL (0.53 mM); Clear solution

    This protocol yields a clear solution of ≥ 0.5 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (5.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.

For the following dissolution methods, please prepare the working solution directly. It is recommended to prepare fresh solutions and use them promptly within a short period of time.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  PBS

    Solubility: 0.5 mg/mL (0.53 mM); Clear solution; Need ultrasonic and warming and heat to 60°C

In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.09%

References
Animal Administration
[1]

Mice[1]
A total of 8×106 A2780-1A9 ovarian cells are injected subcutaneously into the right lateral flank of female nu/nu athymic mice. Once tumours are palpable (50 mm3), mice are randomised to receive treatment intraperitoneally with either PBS (3 times/week), 5 mg/kg OTX008 (3 times/week), 6 mg/kg cisplatin (days 1, 8 and 15) or 10 mg/kg docetaxel (days 1, 8 and 15). Tumour size was measured twice weekly with calipers and tumour volume is calculated as 3.14×(width2)/length[1].

MCE has not independently confirmed the accuracy of these methods. They are for reference only.

References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 6 months; -20°C, 1 month. When stored at -80°C, please use it within 6 months. When stored at -20°C, please use it within 1 month.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO / Ethanol 1 mM 1.0670 mL 5.3352 mL 10.6703 mL 26.6758 mL
5 mM 0.2134 mL 1.0670 mL 2.1341 mL 5.3352 mL
Ethanol 10 mM 0.1067 mL 0.5335 mL 1.0670 mL 2.6676 mL
15 mM 0.0711 mL 0.3557 mL 0.7114 mL 1.7784 mL
20 mM 0.0534 mL 0.2668 mL 0.5335 mL 1.3338 mL
25 mM 0.0427 mL 0.2134 mL 0.4268 mL 1.0670 mL
30 mM 0.0356 mL 0.1778 mL 0.3557 mL 0.8892 mL
