2. Metabolic Enzyme/Protease
  3. HIF/HIF Prolyl-Hydroxylase
  4. IOX4

IOX4 is a selective HIF prolyl-hydroxylase 2 (PHD2) inhibitor with an IC50 value of 1.6 nM, induces HIFα in cells and in wildtype mice with marked induction in the brain tissue. IOX4 competes with and displaces 2-oxoglutarate (2OG) at the active site of PHD2.

For research use only. We do not sell to patients.

IOX4 Chemical Structure

IOX4 Chemical Structure

CAS No. : 1154097-71-8

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
 USD 67 In-stock
Solution
10 mM * 1 mL in DMSO USD 67 In-stock
Solid
5 mg USD 61 In-stock
10 mg USD 116 In-stock
50 mg USD 462 In-stock
100 mg USD 787 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 5 publication(s) in Google Scholar

IOX4 Related Antibodies

Top Publications Citing Use of Products

View All HIF/HIF Prolyl-Hydroxylase Isoform Specific Products:

View All Isoforms
HIF-1α HIF

  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

IOX4 is a selective HIF prolyl-hydroxylase 2 (PHD2) inhibitor with an IC50 value of 1.6 nM, induces HIFα in cells and in wildtype mice with marked induction in the brain tissue. IOX4 competes with and displaces 2-oxoglutarate (2OG) at the active site of PHD2[1].

IC50 & Target

IC50: 1.6 nM (PHD2)[1]
In Vitro

IOX4 (1-100 μM; 5 hours) determines the EC50s for HIF1α induction are 114 μM, 86 μM and 49.5 μM in MCF-7, Hep3B and U2OS, respectively[1].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

IOX4 Related Antibodies
Molecular Weight

328.33

Formula

C15H16N6O3
CAS No.
Appearance

Solid

Color

Light yellow to yellow

SMILES

O=C(C1=CC=C(N2NC=C(N3N=NC=C3)C2=O)N=C1)OC(C)(C)C
Shipping

Room temperature in continental US; may vary elsewhere.
Storage
Powder -20°C 3 years
4°C 2 years
In solvent -80°C 1 year
-20°C 6 months
Solvent & Solubility
In Vitro:

DMSO : 50 mg/mL (152.29 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 3.0457 mL 15.2286 mL 30.4572 mL
5 mM 0.6091 mL 3.0457 mL 6.0914 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 1 year; -20°C, 6 months. When stored at -80°C, please use it within 1 year. When stored at -20°C, please use it within 6 months.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: 2.5 mg/mL (7.61 mM); Suspended solution; Need ultrasonic

    This protocol yields a suspended solution of 2.5 mg/mL. Suspended solution can be used for oral and intraperitoneal injection.

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
  • Protocol 2

    Add each solvent one by one:  10% DMSO    90% (20% SBE-β-CD in Saline)

    Solubility: ≥ 2.08 mg/mL (6.34 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.08 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (20.8 mg/mL) to 900 μL 20% SBE-β-CD in Saline, and mix evenly.

    Preparation of 20% SBE-β-CD in Saline (4°C, storage for one week): 2 g SBE-β-CD powder is dissolved in 10 mL Saline, completely dissolve until clear.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
%
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).
The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 99.78%

COA (248 KB) HNMR (207 KB) LCMS (121 KB)

Handling Instructions (2659 KB)
References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 1 year; -20°C, 6 months. When stored at -80°C, please use it within 1 year. When stored at -20°C, please use it within 6 months.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 3.0457 mL 15.2286 mL 30.4572 mL 76.1429 mL
5 mM 0.6091 mL 3.0457 mL 6.0914 mL 15.2286 mL
10 mM 0.3046 mL 1.5229 mL 3.0457 mL 7.6143 mL
15 mM 0.2030 mL 1.0152 mL 2.0305 mL 5.0762 mL
20 mM 0.1523 mL 0.7614 mL 1.5229 mL 3.8071 mL
25 mM 0.1218 mL 0.6091 mL 1.2183 mL 3.0457 mL
30 mM 0.1015 mL 0.5076 mL 1.0152 mL 2.5381 mL
40 mM 0.0761 mL 0.3807 mL 0.7614 mL 1.9036 mL
50 mM 0.0609 mL 0.3046 mL 0.6091 mL 1.5229 mL
60 mM 0.0508 mL 0.2538 mL 0.5076 mL 1.2690 mL
80 mM 0.0381 mL 0.1904 mL 0.3807 mL 0.9518 mL
100 mM 0.0305 mL 0.1523 mL 0.3046 mL 0.7614 mL
