TPE-MI  (Synonyms: Tetraphenylethene maleimide)

Cat. No.: HY-143218 Purity: 98.54%
COA Handling Instructions

Molarity Calculator

TPE-MI (Tetraphenylethene maleimide) is a thiol probe for measuring unfolded protein load and proteostasis in cells. TPE-MI can report imbalances in proteostasis in induced pluripotent stem cell models of Huntington disease, as well as cells transfected with mutant Huntington exon 1 before the formation of visible aggregates. TPE-MI also detects protein damage following dihydroartemisinin research of the malaria parasitesPlasmodium falciparum .

For research use only. We do not sell to patients.

TPE-MI Chemical Structure

TPE-MI Chemical Structure

CAS No. : 1245606-71-6

Size Price Stock Quantity
Free Sample (0.1 - 0.5 mg)   Apply Now
Solid + Solvent
10 mM * 1 mL in DMSO
ready for reconstitution
 USD 165 In-stock
Solution
10 mM * 1 mL in DMSO USD 165 In-stock
Solid
5 mg USD 150 In-stock
10 mg USD 240 In-stock
25 mg USD 480 In-stock
50 mg USD 770 In-stock
100 mg USD 1250 In-stock
200 mg   Get quote
500 mg   Get quote

* Please select Quantity before adding items.

This product is a controlled substance and not for sale in your territory.

Customer Review

Based on 1 publication(s) in Google Scholar

TPE-MI Related Antibodies

Top Publications Citing Use of Products

1 Publications Citing Use of MCE TPE-MI

View All Parasite Isoform Specific Products:

View All Isoforms
Amebae Coccidia Leishmania Mite Plasmodium Toxoplasma Trypanosoma Schistosome

  • Biological Activity

  • Purity & Documentation

  • References

  • Customer Review

Description

TPE-MI (Tetraphenylethene maleimide) is a thiol probe for measuring unfolded protein load and proteostasis in cells. TPE-MI can report imbalances in proteostasis in induced pluripotent stem cell models of Huntington disease, as well as cells transfected with mutant Huntington exon 1 before the formation of visible aggregates. TPE-MI also detects protein damage following dihydroartemisinin research of the malaria parasitesPlasmodium falciparum [1][2].

IC50 & Target

Plasmodium



In Vitro

TPE-MI is inherently non-fluorescent until it is conjugated to a thiol via the maleimide. TPE-MI fluorescence is activated upon labelling free cysteine thiols, normally buried in the core of globular proteins that are exposed upon unfolding[1].
TPE-MI (50 μM; 0-60 min) exhibits a homogeneous cytoplasmic labelling pattern in live HeLa cells, with a lower level of labelling in the nucleus and apparent concentration in the region of the ER, which was anticipated as a major location for protein synthesis and folding[1].
At the high expression level, the mutant 97Q form of Httex1 was associated with an elevated TPE-MI fluorescence signal relative to a non-disease-causing 25Q form of Httex1[1].
TPE-MI consists of the aggregation-induced emission (AIE) fluorogen tetraphenylethane (TPE) and the thiol-reactive group maleimide (MI), thereby possessing both AIE phenomenon and selective thiol reactivity[2].

MedChemExpress (MCE) has not independently confirmed the accuracy of these methods. They are for reference only.

TPE-MI Related Antibodies
Molecular Weight

441.52

Formula

C31H23NO2
CAS No.
Appearance

Solid

Color

Light yellow to yellow

Emission (Em)

470
Excitation (Ex)

350
SMILES

O=C(C=C1)N(C2=CC=C(/C(C3=CC=CC=C3)=C(C4=CC=C(C)C=C4)/C5=CC=CC=C5)C=C2)C1=O
Shipping

Room temperature in continental US; may vary elsewhere.
Storage

4°C, protect from light

*In solvent : -80°C, 2 years; -20°C, 1 year (protect from light)

Solvent & Solubility
In Vitro:

DMSO : 44.15 mg/mL (100.00 mM; Need ultrasonic; Hygroscopic DMSO has a significant impact on the solubility of product, please use newly opened DMSO)

Preparing
Stock Solutions
Concentration Solvent Mass 1 mg 5 mg 10 mg
1 mM 2.2649 mL 11.3245 mL 22.6490 mL
5 mM 0.4530 mL 2.2649 mL 4.5298 mL
View the Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year (protect from light). When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

  • Molarity Calculator

  • Dilution Calculator

Mass (g) = Concentration (mol/L) × Volume (L) × Molecular Weight (g/mol)

Mass
=
Concentration
×
Volume
×
Molecular Weight *

Concentration (start) × Volume (start) = Concentration (final) × Volume (final)

This equation is commonly abbreviated as: C1V1 = C2V2

Concentration (start)

C1

×
Volume (start)

V1

=
Concentration (final)

C2

×
Volume (final)

V2

In Vivo:

Select the appropriate dissolution method based on your experimental animal and administration route.

For the following dissolution methods, please ensure to first prepare a clear stock solution using an In Vitro approach and then sequentially add co-solvents:
To ensure reliable experimental results, the clarified stock solution can be appropriately stored based on storage conditions. As for the working solution for in vivo experiments, it is recommended to prepare freshly and use it on the same day.
The percentages shown for the solvents indicate their volumetric ratio in the final prepared solution. If precipitation or phase separation occurs during preparation, heat and/or sonication can be used to aid dissolution.

  • Protocol 1

    Add each solvent one by one:  10% DMSO    40% PEG300    5% Tween-80    45% Saline

    Solubility: ≥ 2.5 mg/mL (5.66 mM); Clear solution

    This protocol yields a clear solution of ≥ 2.5 mg/mL (saturation unknown).

    Taking 1 mL working solution as an example, add 100 μL DMSO stock solution (25.0 mg/mL) to 400 μL PEG300, and mix evenly; then add 50 μL Tween-80 and mix evenly; then add 450 μL Saline to adjust the volume to 1 mL.

    Preparation of Saline: Dissolve 0.9 g sodium chloride in ddH₂O and dilute to 100 mL to obtain a clear Saline solution.
In Vivo Dissolution Calculator
Please enter the basic information of animal experiments:

Dosage

mg/kg

Animal weight
(per animal)

g

Dosing volume
(per animal)

μL

Number of animals

Recommended: Prepare an additional quantity of animals to account for potential losses during experiments.
Please enter your animal formula composition:
%
DMSO +
%
+
%
Tween-80 +
%
Saline
Recommended: Keep the proportion of DMSO in working solution below 2% if your animal is weak.
The co-solvents required include: DMSO, . All of co-solvents are available by MedChemExpress (MCE). , Tween 80. All of co-solvents are available by MedChemExpress (MCE).
Calculation results:
Working solution concentration: mg/mL
Method for preparing stock solution: mg drug dissolved in μL  DMSO (Stock solution concentration: mg/mL).

*In solvent : -80°C, 2 years; -20°C, 1 year (protect from light)

The concentration of the stock solution you require exceeds the measured solubility. The following solution is for reference only. If necessary, please contact MedChemExpress (MCE).
Method for preparing in vivo working solution for animal experiments: Take μL DMSO stock solution, add μL . μL , mix evenly, next add μL Tween 80, mix evenly, then add μL Saline.
 If the continuous dosing period exceeds half a month, please choose this protocol carefully.
Please ensure that the stock solution in the first step is dissolved to a clear state, and add co-solvents in sequence. You can use ultrasonic heating (ultrasonic cleaner, recommended frequency 20-40 kHz), vortexing, etc. to assist dissolution.
Purity & Documentation

Purity: 98.54%

COA (257 KB) HNMR (262 KB) RP-HPLC (261 KB) LCMS (272 KB)

Handling Instructions (2659 KB)
References

Complete Stock Solution Preparation Table

* Please refer to the solubility information to select the appropriate solvent. Once prepared, please aliquot and store the solution to prevent product inactivation from repeated freeze-thaw cycles.
Storage method and period of stock solution: -80°C, 2 years; -20°C, 1 year (protect from light). When stored at -80°C, please use it within 2 years. When stored at -20°C, please use it within 1 year.

Optional Solvent Concentration Solvent Mass 1 mg 5 mg 10 mg 25 mg
DMSO 1 mM 2.2649 mL 11.3245 mL 22.6490 mL 56.6226 mL
5 mM 0.4530 mL 2.2649 mL 4.5298 mL 11.3245 mL
10 mM 0.2265 mL 1.1325 mL 2.2649 mL 5.6623 mL
15 mM 0.1510 mL 0.7550 mL 1.5099 mL 3.7748 mL
20 mM 0.1132 mL 0.5662 mL 1.1325 mL 2.8311 mL
25 mM 0.0906 mL 0.4530 mL 0.9060 mL 2.2649 mL
30 mM 0.0755 mL 0.3775 mL 0.7550 mL 1.8874 mL
40 mM 0.0566 mL 0.2831 mL 0.5662 mL 1.4156 mL
50 mM 0.0453 mL 0.2265 mL 0.4530 mL 1.1325 mL
60 mM 0.0377 mL 0.1887 mL 0.3775 mL 0.9437 mL
80 mM 0.0283 mL 0.1416 mL 0.2831 mL 0.7078 mL
